CONCEALED LED - HIDE-A-LED - (6 LED) - HEADLIGHT/SURFACE MOUNTABLE -12-24VDC - 16 FLASH PATTERNS - CLEAR

ECCO 9014C – Hide-A-LED® Concealed Directional / Warning LED (Solid Color, 16 Flash Patterns, ≤2 A, Universal Mount)

Upgrade your vehicle’s safety lighting with the ECCO 9014C, a compact, low-profile concealed LED warning light designed for in-headlight, taillight, or surface mounting. This Hide-A-LED® unit delivers intense directional warning without a bulky external housing — perfect for discreet installs. Each 9014C consumes fewer than 2 amps and offers 16 selectable flash patterns, all within a self-adhesive bezel for simple mounting. It’s ideal for securing OEM-style looks while providing robust warning capability.

Key Features & Specifications

• Concealed / low-profile design: installs flush inside headlight, taillight housings, or on flat surfaces using a ½″ drill hole and adhesive bezel
• Solid-color LED warning light with directional output (no color switching)
• 16 flash patterns: various modes like single, double, triple, quad, chase, etc.
• Low current draw: under 2 A in operation
• Universal mounting options: 1″ hole or surface mount configurations via included bezel or adhesive
• Sealed driver and optics: ensures durability and protection from environmental exposure
• Compact size: 1.5″ in length for tight spaces
• Warranty & support: backed by ECCO’s Hide-A-LED product support and typical LED warranties

Applications & Benefits

• Concealed warning light installs within OEM light housings or behind panels
• Ideal for retrofit projects where you want warning light capability without altering exterior aesthetics
• Useful in headlamp, tail lamp, or auxiliary light housings to supplement directional lighting
• Offers discreet but effective warning signaling for emergency, utility, or fleet vehicles
• Low power draw helps preserve battery life in always-on or standby uses

Installation Tips

• Drill a ½″ (or appropriate) hole and insert the light head; use the self-adhesive bezel to secure flush.
• For surface applications, use the included base or gasket to prevent water ingress.
• Route wiring through grommets or sealed pass-throughs to avoid chafing.
• Use appropriate fuse protection (e.g. 5 A) near the power source.
• Test all 16 flash patterns after mounting before final sealing.
• Periodically inspect the lens and wiring in harsh use or off-road conditions.
