LED BEACON - SQUARE - REINFORCED POLYPROPYLENE BASE - LOW PROFILE - 12-24VDC - 8 FLASH PATTERNS - VACUUM MAGNET MOUNT -

Ecco EB7180A-VM LED Beacon — Low-Profile Amber Vacuum-Magnet Mount (12-24 V, 8 Flash Patterns)

Enhance safety on your fleet, work trucks, service vehicles, or utility equipment with the Ecco EB7180A-VM LED beacon. This rugged, low-profile warning light offers SAE Class I output, eight selectable flash patterns (including simulated rotate), and synchronization capability across multiple units. Designed for reliability in harsh conditions, the EB7180A-VM combines high performance, low current draw, and versatile mounting to fit a broad range of mobile lighting applications.

Key Specifications & Features

• Voltage: 12-24 V DC (works across standard vehicle systems)
• Current Draw: ~6.2 A
• Mount Type: Vacuum-magnet mount (with 381 mm cigarette cord & switchable plug)
• Lens Color: Amber (colored)
• Flash Patterns: 8 total (Single, Double, Quad, Rotate at 125 & 75 FPM)
• Synchronization: Multiple beacons can be synchronized for uniform flashing
• Temperature Range: –22 °F to +122 °F (–30 °C to +50 °C)
• Certifications & Ratings: SAE J845 Class I, California Title 13, R10, IP55, AMECA, RoHS
• Warranty: 3 years (standard for EB7180 series)
• Low-profile design: Compact footprint suitable for tight mounting spaces

Why Choose the EB7180A-VM?

• Versatile operation: Accepts both 12 V and 24 V systems, ideal for mixed fleets or retrofits
• Flexible mounting: Vacuum-magnet mount allows temporary or semi-permanent placement without drilling
• High visibility with efficiency: SAE Class I output with multiple flash modes while managing current draw
• Durable & weather-resistant: Built to withstand outdoor conditions and vibration environments
• Synchronized lighting: Multiple units can be wired to flash in unison — especially useful on larger vehicles

Applications

• Utility and service trucks
• Tow and recovery vehicles
• Road maintenance and snowplow operations
• Municipal vehicles (e.g. street sweepers, sign trucks)
• Rental or contractor fleets needing portable warning lighting

Installation Tips & Notes

• Clean and level mounting surface before applying magnet to optimize adhesion.
• Confirm firm contact of the vacuum-magnet to metal surface to ensure signal stability.
• Use proper gauge wire and fusing to protect the circuit.
• For synchronized operation, follow ECCO wiring schematics to ensure all units flash in unison.
• Avoid mounting in extreme heat zones (near exhausts) to maintain longevity.

With its performance, flexible mounting, and rugged design, the Ecco EB7180A-VM is a versatile and dependable choice for warning and safety lighting in mobile environments.
