LED BEACON - SQUARE - REINFORCED POLYPROPYLENE BASE - LOW PROFILE - 12-24VDC - 8 FLASH PATTERNS - AMBER
ECCO EB7180A LED Beacon — Low-Profile Amber, 4-Bolt Flange Mount (12–24 V, 8 Flash Patterns, SAE Class I)
The ECCO EB7180A is a compact, high-performance warning beacon engineered for industrial, utility, fleet, and emergency vehicle applications. With SAE Class I output, 8 selectable flash patterns (including simulated rotate), and synchronization support, it delivers powerful visual warning while maintaining efficiency and durability. Designed to outlast traditional strobe or rotating lights, the EB7180A is a reliable, maintenance-free lighting solution.
Key Features & Specifications
- Voltage: 12 V – 24 V DC (works on standard vehicle systems)
- Current Draw: 6.2 A
- Flash Patterns (8):
- Single, 125 FPM
- Double, 125 FPM
- Quad, 125 FPM
- Rotate, 125 FPM
- Single, 75 FPM
- Double, 75 FPM
- Quad, 75 FPM
- Rotate, 75 FPM
- Mounting Style: 4-bolt flange mount (fixed installation)
- Lens / Illumination: Amber (single-color)
- Dimensions: 2.3 in height × 6.5 in length/width (approx)
- Temperature Range: –22 °F to +122 °F (–30 °C to +50 °C)
- Protection & Ratings: IP55, SAE J845 Class I, California Title 13, R10, AMECA, RoHS compliance
- Warranty: 3 years
Why the EB7180A Stands Out
- High visibility, efficient performance: Offers SAE Class I warning output while consuming only 6.2 A, making it suitable for repeated use without excessive power drain
- Robust build: Sealed design and durable materials ensure reliability in demanding work environments
- Flash flexibility: Eight selectable patterns (including simulated rotate) give you control over how your warning signal behaves
- Synchronization capability: When using multiple units, they can be wired to flash in sync for cohesive visual alerting
- Direct retrofit option: Designed to replace older strobe or rotating beacons with a modern, lower-maintenance solution
Recommended Applications
- Fleet trucks, utility vehicles, service & repair trucks
- Municipal and public works vehicles
- Tow and recovery rigs
- Construction, road maintenance, and safety zones
- Anywhere high-intensity warning lighting is needed
Installation & Usage Tips
- Use the proper bolt pattern and torque to secure the flange mount to the vehicle surface.
- Match wiring to your vehicle’s voltage system and ensure adequate fuse protection.
- If synchronizing multiple beacons, follow ECCO’s recommended wiring diagrams.
- Avoid mounting near engine exhaust or high heat zones to preserve beacon life.
- Periodically inspect for moisture intrusion and ensure seal integrity.
Upgrade your fleet’s warning capability with the ECCO EB7180A — a durable, efficient LED beacon that delivers class-leading warning performance with low maintenance requirements.
