LED BEACON - SQUARE - REINFORCED POLYPROPYLENE BASE - MEDIUM PROFILE - 12-24VDC - 24 FLASH PATTERNS - CLEAR

ECCO EB7185CCC LED Beacon — Clear / Clear / Clear, 4-Bolt Flange Mount (12-24 V, 24 Flash Patterns, SAE Class I)

Upgrade your lighting system with the ECCO EB7185CCC, a high-performance, maintenance-free LED warning beacon. Part of ECCO’s EB7185 series, this model features a clear lens on all faces (Clear/Clear/Clear) for maximal light output, robust SAE Class I warning intensity, and 24 selectable flash patterns, including simulated rotate and synchronization capability with multiple units. Designed for 12–24 V DC systems, it draws ~8.6 amps and is sealed against weather and vibration. Ideal for emergency vehicles, work trucks, safety fleets, and mobile applications.

Key Features & Specifications

• Voltage: 12 – 24 V DC
• Current Draw: ~ 8.6 A
• Flash Patterns: 24 modes including simulated rotate, hi/lo intensity, and synchronization
• Mounting: 4-bolt flange mount (permanent install)
• Lens / Color: Clear on all sides (no amber)
• Dimensions: ~ 3.3 in height × 6.5 in width (approx)
• Ratings & Approvals: SAE Class I, R10, IP55, AMECA, RoHS
• Temperature Range: –22 °F to +122 °F (–30 °C to +50 °C)
• Warranty: 3 years (standard for EB7185 series)

Why Choose the EB7185CCC?

• Maximum brightness: Clear lens on all faces ensures the full LED output is visible without color filtering
• Flash flexibility: 24 flash modes let you tailor the warning signature for different situations
• Sync ready: Multiple beacons can be wired to flash in unison for a consistent fleet look
• High performance: Delivers SAE Class I warning output in a robust, sealed design
• Retrofit ready: Can replace strobe or rotating beacons to provide superior reliability and lower maintenance

Typical Applications

• Emergency / police / fire vehicles
• Utility, construction, and service trucks
• Municipal / public works fleets
• Tow / recovery vehicles
• Work zones, safety operations, and mobile warning setups

Installation Tips & Best Practices

• Choose a flat, rigid mounting surface and verify the 4-bolt hole pattern matches.
• Use proper gauge wire, protect against abrasion, and fuse the circuit appropriately.
• Ensure the ground is solid and the beacon is mounted level to avoid light distortion.
• When synchronizing multiple units, follow ECCO’s wiring guidelines to ensure correct timing.
• Periodically inspect lens clarity, mounting hardware torque, and seal integrity in harsh environments.

Bring high-output, configurable warning light performance to your fleet with the ECCO EB7185CCC — clear-lens precision, powerful flash control, and rugged LED reliability.
