DIRECTIONAL - LED - 24in OUTLINER PERIMETER BAR - LEFT WIRE EXIT - 12VDC - DUAL-COLOR - BLUE/WHITE-RED/WHITE

ECCO ED3724BWRW-L — 24″ Dual-Color Directional Outliner Bar (Blue/White + Red/White, Left Wire Exit, 12 V DC)

Expand your vehicle’s visual presence with the ECCO ED3724BWRW-L, a 24" outliner / perimeter LED bar combining dual-color (Blue/White and Red/White) directional lighting capabilities in one unit. Designed for flush mounting, this left-wire-exit bar is perfect for running board, bumper, or tailgate installations. It offers 32 selectable flash patterns—including steady-burn, dual-color sequencing, and traffic advisor modes—and sync capability with other ECCO directional modules. With sealed LEDs, a rugged aluminum housing, and full ECCO-quality construction, it’s built for demanding field use.

Key Features & Specifications

• Length: 24″ outliner / perimeter style LED bar
• Dual-Color: Blue/White + Red/White integrated in one unit
• Operating Voltage: 12 V DC nominal
• Selectable Flash Patterns: 32 modes, including steady, color switching, traffic advisor, etc.
• Left Wire Exit: Wiring conveniently exits the left side for easier routing
• Housing & Durability: Powder-coated aluminum body, sealed LED heads, IP-rated for moisture and dust protection
• Mounting: Universal surface-mount design for flush integration on flat surfaces
• Sync & Override: Includes wiring for sync (Phase 1 / Phase 2), steady override, dimming, and pattern select
• Approvals / Ratings: Classified ratings for classes of directional use (Class 2 / Class 3) per ECCO drawing documentation
• Dimensions & Mounting Details: From ECCO technical drawing: mount holes, physical layout, output mappings for power, sync, etc.

Why It’s a Strong Choice

• Combines blue/white and red/white output in a single bar—no need for two separate fixtures
• Provides strong edge / side-line visibility with directional functionality
• Left-wire exit helps in streamlined wiring and installation in many vehicle layouts
• Built with rugged, sealed components suitable for exterior exposure and vibration
• Offers excellent flexibility with many flash patterns and sync capabilities

Typical Applications

• Running-board or bumper outliner lighting for emergency or patrol vehicles
• Tailgate / hatch perimeter accent + directional lighting
• Vehicle side panels or body edges needing flush, high-visibility lighting
• Retrofit installs on utility or service trucks that require dual-color directional bars
• Coordinated lighting systems using multiple ECCO directional modules

Installation & Best Practices

• Identify a clean, flat mounting surface for the bar, ensuring no obstruction to light output.
• Use proper grommets or bulkhead seals where wire exits pass through body panels.
• Route wires away from heat sources, sharp edges, or pinch points.
• Use correct gauge wire and fuse protection near the power source.
• Ground to a solid chassis point for reliable operation and minimal flicker.
• Before final mounting, test all flash patterns, dual-color modes, and sync functionality.
• Inspect periodically—check lens, mounting bolts, wiring and seal condition—especially after heavy use or off-road exposure.
