DIRECTIONAL - LED - 36in OUTLINER PERIMETER BAR - LEFT WIRE EXIT - 12VDC - DUAL-COLOR - BLUE/WHITE-RED/WHITE

ECCO ED3736BWRW-L — 36″ Dual-Color Directional Outliner LED Bar (Blue/White & Red/White, 12 V DC, Left Wire Exit, Class I)

Extend your vehicle’s visual coverage with the ECCO ED3736BWRW-L, a 36-inch directional outliner / perimeter LED bar that delivers dual-color flexibility and robust warning performance. This left-wire exit model outputs both blue/white and red/white lighting modes, giving fleets the ability to adapt color signals as needed. Built for 12 V DC systems, it’s ideal for integration into emergency, utility, service, and fleet vehicles looking for enhanced side and edge visibility.

Key Features & Specifications

• Length: 36″ (outliner / perimeter bar format)
• Color Modes: Dual-color: Blue/White and Red/White (in one unit)
• Voltage: 12 V DC operation (common for vehicle lighting systems)
• Wire Exit: Left-wire exit configuration for flexible installation routing
• Durability & Housing: High-grade aluminum body, sealed LED heads, IP67-style protection (sealed against moisture)
• Flash / Synchronization: Supports phase 1 & phase 2 sync capabilities, includes separate wires for dim and steady burn override
• Mounting Options: Meant to be surface mounted along edges, running boards, push bumpers, tailgates, or side mirrors
• Approvals: Meets standards such as SAE Class I, California Title 13, IP67, RoHS compliance
• Warranty: Backed by a 5-year warranty

Why Choose the ED3736BWRW-L?

• Combines dual-color output (blue/white + red/white) in one long bar — cuts down on extra fixtures
• Ideal for perimeter / outliner usage to improve side visibility on vehicles
• Left-wire exit allows cleaner wiring paths on many vehicle layouts
• Durable sealed construction handles elements and road vibration
• Sync capabilities align the bar’s flashing with other ECCO directional modules
• 36″ span makes it ideal for long side or rear runs

Typical Applications

• Outliner / perimeter lighting on emergency / service trucks
• Side covers, running boards, edges of truck bodies
• Integration into auxiliary lighting systems for fleets
• Retrofit or OEM installations where continuous edge lighting is desired
• Use in coordinated lighting systems with synchronized directional bars

Installation Tips

• Plan mounting along flat, clean edges with minimal obstruction to the LED output.
• Use grommets or bulkhead seals where wiring passes through body panels.
• Route the left-side cable exit carefully to avoid sharp edges, heat, or pinch zones.
• Use proper wire gauge and fuse protection near the battery or power source.
• Ensure a solid ground connection to prevent flicker or electrical noise.
• Test color modes and sync behavior before final securing of the bar.
• Secure mounting hardware tightly but allow for periodic inspection, especially in high-vibration environments.
