DIRECTIONAL - LED - 60in OUTLINER PERIMETER BAR - LEFT WIRE EXIT - 12VDC - DUAL-COLOR - AMBER/WHITE

ECCO ED3760AW-L — 60″ Dual-Color Directional Outliner / Perimeter LED Bar (Amber / White, Left Wire Exit, 12 V DC)

Enhance your vehicle’s visibility with the ECCO ED3760AW-L, a robust 60-inch dual-color directional outliner bar. Designed for perimeter, running board, push bumper, or tailgate mounting, this high-output LED bar combines amber and white modes in one seamless fixture. With 32 customizable flash patterns (including steady-burn and dimming modes), phase synchronization, and rugged construction, the ED3760AW-L delivers both style and function for fleet, emergency, service, and utility vehicles.

Key Features & Specifications

• Length: 60″ (5 ft) directional outliner / perimeter bar
• Dual-Color Output: Amber / White selectable modes in one unit
• Wire Exit: Left-wire exit configuration for wiring flexibility
• Voltage: 12 V DC (standard for ECCO outliner products)
• Flash / Modes: 32 flash patterns including steady burn and dimming
• Mounting: Universal surface-mount design for flush integration onto vehicle surfaces
• Housing & Durability: Powder-coated aluminum housing, sealed LED heads, durable polycarbonate lens, weather-resistant design
• Sync Capability: Phase 1 / Phase 2 synchronization and wiring for override / dim functionality
• Warranty & Compliance: Backed by ECCO’s 5-year no-hassle warranty; designed to meet rigorous lighting and durability standards

Why Choose the ED3760AW-L?

• Offers amber and white in one bar—simplifies installation while giving flexibility
• 60" coverage length makes it ideal for long perimeter or side installations
• High number of flash modes and sync support allow tailored visual signaling
• Rugged build and sealed optics ensure long-term reliability in demanding environments
• Left-wire exit helps with cleaner wiring layouts on many vehicle designs

Typical Applications

• Running boards, side skirts, body edges on trucks and vans
• Tailgate, bumper, or step bumper perimeter lighting
• Outliner / buffer zone lighting for emergency and fleet vehicles
• Supplemental side or edge lighting to complement main lightbars
• Retrofit or new installations where amber/white dual-color is desired

Installation Tips

• Choose a flat, clean mounting surface that allows full light emission.
• Use grommets or protective sleeves at panel penetrations to avoid chafe.
• Route wiring carefully to avoid pinch points, heat, or interference sources.
• Fuse the power feed near the 12V source to protect wiring and components.
• Program your preferred flash mode and verify color switching before final mounting.
• Ground to a clean chassis point to avoid flicker or electrical noise.
• If using multiple bars, follow ECCO’s recommended wiring layout for synchronization.
• Inspect lenses, mounting hardware, and wiring regularly, especially in high-vibration or off-road use.
