DIRECTIONAL - LED - 60in OUTLINER PERIMETER BAR - RIGHT WIRE EXIT - 12VDC - DUAL-COLOR - AMBER/WHITE

ECCO ED3760AW-R — 60″ Dual-Color Directional Outliner Bar (Amber / White, Right Wire Exit, 12 V DC)

Boost your vehicle’s perimeter visibility with the ECCO ED3760AW-R, a full-length 60-inch (61.3″ nominal) directional outliner LED bar. Built for rugged use, this dual-color bar delivers both amber and white output modes, letting you switch between high-visibility warning and work lighting in a single unit. It features a right-wire exit design to accommodate wiring layouts cleanly. With 32 dual-color flash patterns, steady burn override, and phase synchronization (Phase 1 / Phase 2), this bar is engineered for seamless integration. Constructed with a powder-coated aluminum housing, sealed LED heads, and a robust polycarbonate lens, the ED3760AW-R is ready for demanding environments. It also includes a generous 55" jacketed cable and is backed by ECCO’s 5-year no-hassle warranty.

Key Features & Specs

• Dual-Color Output: Amber / White in a single bar — convenient for multi-mode signaling
• Flash Patterns & Sync: 32 selectable patterns including steady, chase, alternation, plus sync support for multi-bar systems
• Mount / Wiring Exit: Right-wire exit configuration for optimized route in many installations
• Housing & Durability: Powder-coated aluminum frame, sealed light heads, scratch-resistant lens, weather- and vibration-resistant build
• Voltage & Power Specs: Operates on 12 V DC, includes 55" jacketed cable; includes dim / override wiring
• Mounting Versatility: Universal surface mount for flush application on running boards, bumpers, tailgates, or body edges
• Warranty & Support: Covered by ECCO’s 5-year no-hassle warranty

Ideal Applications

• Outliner / edge lighting on trucks, SUVs, emergency vehicles
• Side accent, body perimeter, or tailgate lighting
• Supplementary lighting integrated with main LED systems
• Retrofit or new installs where dual-color directional lighting is desired

Installation Tips

• Choose a straight, flat surface for maximum light emission.
• Use grommets or sealed pass-throughs where the cable passes through bodywork.
• Route right-exit cable away from pinch or heat zones.
• Fuse and gauge your power line appropriately close to source.
• Test flash modes and color switching before securing final mounts.
• Ground to a clean chassis point to reduce flicker or noise.
• Inspections every service interval—check lens, mounts, and wiring integrity.
