DIRECTIONAL - LED - 60in OUTLINER PERIMETER BAR - RIGHT WIRE EXIT - 12VDC - DUAL-COLOR - RED/WHITE

ECCO ED3760RW-R — 60″ Dual-Color Directional Outliner Bar (Red / White, Right Wire Exit, 12 V DC)

Enhance your vehicle’s visibility and warning presence with the ECCO ED3760RW-R, a full-length 61.3″ (approx. 60″ class) outliner / perimeter directional LED bar offering dual-color (red / white) output in one rugged fixture. Designed for perimeter mounting on running boards, bumpers, or body edges, this bar includes 32 dual-color flash patterns, a right-wire exit design for cleaner routing, and compatibility with Phase 1 / Phase 2 sync systems. With a powder-coated aluminum housing, sealed light heads, IP67-rated construction, and a 5-year warranty, the ED3760RW-R is built for demanding field conditions.

Key Features & Specifications

• Full-length 61.3″ bar for broad perimeter lighting coverage
• Dual-color (Red / White) output — switch between warning or auxiliary white modes
• Right-wire exit configuration for convenient cable routing
• 32 flash modes — dual-color sequencing, steady-burn, color alternation, and traffic advisor modes
• Supports synchronization (Phase 1 / Phase 2) to coordinate flashing with other directional modules
• Universal surface-mount design — flush mountable on body panels, bumpers, or running boards
• Durable, powder-coated aluminum frame with sealed light heads and IP67 dust / water protection
• Includes 55" jacketed cable and separate wiring for dim/steady override modes
• Rated at 12 V DC, current ~0.6 A under typical operation
• Certified to SAE / Class II, California Title 13, RoHS standards
• Backed by ECCO’s 5-year warranty on the unit

Typical Use Cases

• Outliner / perimeter lighting on police, fire, EMS, or utility vehicles
• Body-edge accent lighting, running boards, bumper lines
• Complementary lighting synchronized with primary directional modules
• Retrofit or custom builds requiring dual-color directional output

Installation Tips

• Place the bar on a flat, unobstructed mounting surface to maximize coverage.
• Use grommets or sealed entry points where the wire passes through body panels to maintain watertight integrity.
• Route the right-exit cable carefully away from pinch points or heat zones.
• Fuse the power lead close to the 12 V source and use proper gauge wiring.
• Test flash modes, color switching, and sync behavior before final mounting.
• Ensure a clean chassis ground to reduce flicker or electrical noise.
• Periodically inspect the lens, mounting hardware, and wiring, especially in off-road or vibration-prone use.
