SKU
ED3766AG
Manufactures SKU
ECCO ED3766AG
DIRECTIONAL LED - DUAL-COLOR - SURFACE MOUNT - 12-24VDC - 12 FLASH PATTERNS - AMBER/GREEN
$131.76
EA
ECCO ED3766AG Dual-Color Directional LED Warning Light | Amber/Green, SAE Class I Surface Mount
Maximize visibility and double your warning power with the ECCO ED3766AG Dual-Color Directional LED. This compact, high-intensity surface-mount warning light is engineered for superior safety on trucks, utility vehicles, and municipal fleets that require dual-color signaling. The unit combines Amber and Green light outputs into a single low-profile housing, allowing you to create an effective multi-color system with fewer physical lights.
The ED3766AG utilizes 12 high-intensity LEDs (6 of each color) to achieve SAE Class I light output, ensuring maximum brightness and attention-grabbing performance. It features a selection of up to 69 flash patterns and full synchronization capability, allowing you to program the unit to flash each color individually, alternate between the two, or operate simultaneously with other lights.
Built to endure the harshest conditions, the light features a durable aluminum housing, a robust polycarbonate lens, and encapsulated electronics. With an impressive IP67/IP69K rating, it is completely protected against dust ingress, water immersion, and high-pressure/high-temperature spray. Installation is straightforward with the 2-Bolt surface mount design.
Key Features & Specifications:
Maximize visibility and double your warning power with the ECCO ED3766AG Dual-Color Directional LED. This compact, high-intensity surface-mount warning light is engineered for superior safety on trucks, utility vehicles, and municipal fleets that require dual-color signaling. The unit combines Amber and Green light outputs into a single low-profile housing, allowing you to create an effective multi-color system with fewer physical lights.
The ED3766AG utilizes 12 high-intensity LEDs (6 of each color) to achieve SAE Class I light output, ensuring maximum brightness and attention-grabbing performance. It features a selection of up to 69 flash patterns and full synchronization capability, allowing you to program the unit to flash each color individually, alternate between the two, or operate simultaneously with other lights.
Built to endure the harshest conditions, the light features a durable aluminum housing, a robust polycarbonate lens, and encapsulated electronics. With an impressive IP67/IP69K rating, it is completely protected against dust ingress, water immersion, and high-pressure/high-temperature spray. Installation is straightforward with the 2-Bolt surface mount design.
Key Features & Specifications:
- Part Number: ED3766AG
- Light Type: Dual-Color Directional LED Warning Light (ED3766 Series)
- Light Colors: Amber and Green (6 LEDs of each color, 12 Total)
- Mounting: 2-Bolt Surface Mount
- Voltage: 12-24 VDC
- Current Draw: 0.8 Amps (Max)
- Flash Patterns: Up to 69 Selectable Patterns
- Standards: SAE Class I, CA Title 13, ECE R65, IP67, IP69K
- Housing/Lens: Aluminum Housing / Clear Polycarbonate Lens
- Features: Synchronizable, Alternating or Single-Color Flash Modes
Shipping Weight (lbs)
0.480000
Total Height
2
Total Width
7
