DIRECTIONAL - LED - 72in OUTLINER PERIMETER BAR - LEFT WIRE EXIT - 12VDC - DUAL-COLOR -BLUE/WHITE

ECCO ED3772BW-L — 72″ Dual-Color Directional Outliner / Perimeter LED Bar (Blue / White, Left Wire Exit, 12 V DC)

Expand your vehicle’s visibility with the ECCO ED3772BW-L, a high-output 72″ directional outliner bar built to deliver both blue and white warning lighting in one integrated fixture. Ideal for installations along running boards, push bumpers, tailgates, or body edges, this bar features a left-wire exit, universal surface-mount capability, and robust construction. With support for 32 dual-color flash patterns, steady-burn white override, and Phase 1 / Phase 2 synchronization, it’s designed for fleets, emergency vehicles, and utility rigs demanding high visibility in demanding conditions. From the spec sheet: each 12″ segment supports dual-color modes, 32 flash combinations, 1.1 A draw at 12 V, powder-coated aluminum housing, sealed light heads, IP67 rating, 55" cable, and a 5-year warranty.

Key Features & Specifications

• Length: 72″ (nominal); 73.3″ overall length in some listings
• Colors / Modes: Dual-color output — Blue / White
• Mount / Wiring: Left-wire exit for convenient cable routing
• Voltage / Current: 12 V DC; ~1.1 A draw for full bar operation
• Flash / Sync: 32 selectable dual-color flash patterns; steady white override; sync support (Phase 1 & 2)
• Housing & Durability: Powder-coated aluminum frame, sealed lightheads, IP67 environmental rating for dust/moisture protection
• Cable & Connectivity: Supplied with 55" jacketed cable; separate wires for dimming & steady-burn override functions
• Certifications & Warranty: Meets SAE Class III, California Title 13 (T13), IP67, RoHS; backed by a 5-year warranty
• Dimensions / Form: Bar profile ~0.88″ (height) × 2.5″ (width) cross-section

Why Choose the ED3772BW-L?

• One bar offering both blue and white lighting—reduces need for multiple units
• Long perimeter coverage with a sleek, flush-mount footprint
• Flash mode flexibility plus sync capability for multi-bar systems
• Robust design to survive harsh outdoor and roadway environments
• Left-wire exit simplifies installation on many vehicle layouts

Typical Applications

• Roofline, running board, or side-edge lighting on emergency, utility, or fleet vehicles
• Tailgate or bumper perimeter illumination
• Supplemental lighting to support main lightbars
• Retrofit or new build installations where dual-color directional coverage is desired

Installation Tips

• Choose a straight, flat surface to mount the bar so the light output is unobstructed.
• Use grommets or sealed routing at panel penetrations to maintain environmental integrity.
• Route wiring from the left exit away from pinch points, heat sources, or sharp edges.
• Use proper wire gauge and fuse the feed at source to protect wiring and module.
• Program your preferred flash modes and test color switching (blue/white) before final mounting.
• Ground securely to a clean chassis point to avoid flicker or interference.
• Periodically inspect lens, mount hardware, and wiring integrity in high-vibration or outdoor use.
