SKU
ED3779R
Manufactures SKU
ECCO ED3779R
DIRECTIONAL LED - TRIPLE STACK - SINGLE COLOR CENTER 180 DEGREE WARNING - WHITE FLOOD OUTER - MULTI-MOUNT - 12-24VDC -
$248.65
EA
ECCO ED3779R Red Triple Stack Directional LED – 180° Warning Light, White Flood, SAE Class I, 12-24V
The ECCO ED3779R is a powerful, single-color Red directional LED warning light essential for fire apparatus, emergency vehicles, and authorized response fleets. As a part of the ED3779 Triple Stack Series, this robust unit provides maximum warning visibility and scene illumination in a single, low-profile assembly.
Featuring a triple stack configuration, the ED3779R produces an ultra-bright, 180-degree wide-angle light spread, ensuring maximum visibility from the side and off-angle positions. The primary function is a highly effective Red flash using 29 selectable flash patterns for compliance and customization. A separate steady-burn override allows the outer LEDs to function as a powerful White floodlight/worklight, providing necessary illumination for accident scenes or nighttime operations.
This light head meets stringent industry standards including SAE Class I and R65. Its multi-surface mounting options, combined with a durable, completely sealed design (IP67/IP69K rated), make it highly resistant to harsh weather, dust, and pressure washing. The ED3779R operates reliably on all 12-24 VDC truck and vehicle electrical systems.
Key Features & Specifications:
The ECCO ED3779R is a powerful, single-color Red directional LED warning light essential for fire apparatus, emergency vehicles, and authorized response fleets. As a part of the ED3779 Triple Stack Series, this robust unit provides maximum warning visibility and scene illumination in a single, low-profile assembly.
Featuring a triple stack configuration, the ED3779R produces an ultra-bright, 180-degree wide-angle light spread, ensuring maximum visibility from the side and off-angle positions. The primary function is a highly effective Red flash using 29 selectable flash patterns for compliance and customization. A separate steady-burn override allows the outer LEDs to function as a powerful White floodlight/worklight, providing necessary illumination for accident scenes or nighttime operations.
This light head meets stringent industry standards including SAE Class I and R65. Its multi-surface mounting options, combined with a durable, completely sealed design (IP67/IP69K rated), make it highly resistant to harsh weather, dust, and pressure washing. The ED3779R operates reliably on all 12-24 VDC truck and vehicle electrical systems.
Key Features & Specifications:
- Part Number: ECCO ED3779R
- Color: Single-Color Red Warning (with White Floodlight/Worklight Function)
- Light Function: 180-Degree Directional Warning & Scene/Flood Lighting
- LED Rows: Triple Stack Design
- Flash Patterns: 29 (Single-Color Mode)
- Mount Type: Multi-Surface / Surface Mount
- Voltage: 12-24 VDC (Dual Voltage)
- Amps: 1.7 Amps Max
- Approvals: SAE Class I, R65, IP67/IP69K
- Dimensions (Approx.): 5.1" L x 3.4" H x 1.3" D
- Warranty: 5-Year ECCO Warranty
Shipping Weight (lbs)
0.900000
Total Height
4
Total Width
6
