DIRECTIONAL COMBO LED BAR - 135-DEG SIDE WARNING DUAL-COLOR RED/WHITE WITH CENTER WHITE WORKING LIGHT - 12-24VDC

ECCO ED9215RW — 13.6″ Combo LED Warning & Work Light (Red / White, 135° Side-Spread, 12–24 V, Class I Directional)

The ECCO ED9215RW brings together powerful warning and utility lighting in a single compact package. This 13.6-inch combo LED bar delivers dual-color output—red for warning/directional use and white for work/area illumination—offering flexibility and high visibility across the job site or road. With a 135° side spread, this light covers wide angles for effective coverage. It’s compatible with both 12 V and 24 V DC systems, certified SAE Class I, and built with rugged materials and sealed optics to withstand tough conditions. The ED9215RW includes mounting options (tilting pedestal or surface mount) and is ideal for emergency, utility, service, and fleet vehicles.

Key Features & Specifications

• Dual-Color Output (Red / White): Ideal for directional warning + work lighting in one housing
• 135° wide-angle spread for broad side emission
• Voltage range: 12-24 V DC for broad vehicle compatibility
• Light output: ~2,350 lumens in white mode
• Compact form: 4.0″ H × 13.6″ W × 2.7″ D
• Mounting options: tilting pedestal or tilting surface mount
• Certifications: SAE Class I directional, California Title 13, R10, IP67, RoHS, CISPR 25
• Sealed optics and durable housing for harsh conditions

Why Choose ED9215RW?

• Combines red warning light and white work light in one fixture — reduces hardware needs
• Broad 135° spread ensures strong side coverage
• Dual-voltage flexibility (12/24 V) suits mixed fleets
• Certified for directional use (Class I) gives confidence in compliance
• Rugged design and sealed optics built for longevity

Use Cases & Applications

• Mounted on bumpers, grills or work vehicle fronts for combined warning and scene lighting
• Retrofit option replacing separate warning & work fixtures
• Utility, emergency, service, or fleet vehicles where space is limited
• Environments requiring a compact yet high-output combo LED light

Installation Tips

• Mount on a flat, unobstructed surface to maximize light projection.
• Use grommets or conduit for wiring to protect against abrasion or heat.
• Fuse the input close to battery and use adequate wire gauge.
• Orient mounting (tilt or surface) for best balance of warning & work beam coverage.
• Periodically inspect lens, mounting, and connections to maintain performance.
