EMERGENCY LIGHTING - AMBER/BLUE - LED BEACON S.A.E. CLASS I 12 TO 24 VOLT HIGH LENS

Grote 78010 Amber/Blue Tall Dome LED Beacon – SAE Class I Dual Color, Permanent Mount, 12V/24V

Superior Visibility with Dual-Color Versatility The Grote 78010 Amber/Blue Tall Dome LED Beacon is a heavy-duty warning solution engineered for maximum optical impact. Standing at nearly 8 inches tall, this high-profile beacon ensures your vehicle is visible even over obstructions. Featuring dual-color LED technology, it allows operators to toggle between Amber and Blue or isolate specific colors to meet various municipal, emergency, or utility requirements. Rated as SAE J845 Class I, this beacon provides the highest level of light intensity required for authorized emergency and maintenance vehicles.

Advanced S-Link™ Synchronization Take control of your vehicle's lighting profile with the integrated S-Link™ System. This proprietary technology allows you to synchronize the 78010 with up to six other S-Link compatible units. Whether you need alternating or simultaneous flashes, S-Link enables a coordinated, professional look across your entire fleet. With 12 selectable flash patterns, including two rotating patterns and a steady-on mode, you can customize the signal to suit any hazard or environment.

Built for the Extreme Professional Environment Durability is at the core of the 78010. It features a heavy-duty spun aluminum base with a plastic insert for added structural integrity and a rugged polycarbonate lens that resists impact and UV degradation. The internal circuit boards are conformal coated to protect against moisture, shock, and vibration. Designed for a universal 12V/24V system, this beacon is the perfect upgrade for heavy-duty trucks, snowplows, and emergency response vehicles.

Key Features:

• SAE J845 Class I Rated: Professional-grade intensity for emergency and utility use.
• Dual-Color Performance: Amber and Blue LEDs with the ability to isolate colors.
• S-Link™ Technology: Synchronize with up to 6 compatible units for a unified flash sequence.
• 12 Flash Patterns: Includes 2 rotating patterns and 2 phases per pattern.
• Tall Dome Design: 7.9" height for maximum 360-degree visibility over vehicle components.
• Heavy-Duty Construction: Spun aluminum base and polycarbonate dome for maximum lifespan.
• Conformal Coated Electronics: Protects internal circuitry from vibration and corrosion.

Specifications:

• Part Number: 78010
• VMRS Code: 034-006-056
• Voltage: 12V / 24V DC
• Amperage: 0.6A @ 12V / 0.3A @ 24V
• Mounting Type: 3-Hole Permanent Mount / 1" Pipe Mount
• Lens Color: Clear (Outer Dome) / Amber & Blue (Internal)
• Standards: SAE J845 Class I
• Dimensions: 8.9" Width x 7.9" Height
• Warranty: 5-Year Manufacturer Warranty
