Pollak 11-409 4-Way Round Trailer Connector Plug - Heavy-Duty Chrome Die-Cast Zinc

The Ultimate Heavy-Duty Trailer-Side Connection The Pollak 11-409 4-Way Round Trailer Plug is a professional-grade electrical connector designed for those who demand more than standard plastic hardware. Built for the trailer-side of your electrical system, this plug is ideal for utility trailers, marine applications, and light-duty commercial towing where a rugged, reliable connection is non-negotiable.

Unrivaled Durability & Corrosion Resistance Encased in a premium chrome-plated zinc die-cast housing, the 11-409 is engineered to survive harsh road environments and salt-heavy marine conditions. Inside, it features high-impact green ABS thermoplastic insulators and split-brass contacts. These contacts ensure maximum electrical conductivity and a secure "tension-fit" that resists vibration and accidental disconnection while you're on the move.

Simplified Installation & Use Pollak has designed this plug with the user in mind. It features a unique internal cable clamp that provides superior cable support, preventing wire chafing and strain. The exterior is tapered with integral finger grips, making it easy to plug and unplug even while wearing heavy gloves. With its polarized design, you can trust that your wiring will align perfectly every time, protecting your lighting system from shorts and cross-connections.

Key Features & Benefits:

• Heavy-Duty Construction: Rugged chrome-plated die-cast zinc housing for maximum service life.

• High Conductivity: Split-brass contacts provide superior electrical flow and a secure mechanical fit.

• Weather & Impact Resistant: Features high-impact green insulators and a dust/water-resistant design.

• Cable Support System: Integrated internal clamp saves installation time and prevents wire strain.

• Easy Handling: Tapered design with built-in finger grips for a positive pull.

• Marine Grade: Ideal for boat trailers and other high-moisture towing environments.

Technical Specifications:

• Part Number: 11-409 (11-409P)

• Connection Type: 4-Pole Round Pin (Trailer Side)

• Voltage Rating: 12-24 Volts DC

• Current Rating: 20 Amps

• Material: Chrome-Plated Zinc Die-Cast

• Insulator: High-Impact Green ABS Thermoplastic

• Interchange: Fits standard 4-way round sockets (Commonly paired with Pollak 11-410 socket).
