Pollak 11-608 6-Way Round Trailer Connector Socket with Protective Rubber Boot

Ultimate Weather Protection for Vehicle-Side Wiring The Pollak 11-608 6-Way Round Socket takes the reliable performance of the classic 6-pole design and adds a critical layer of defense: a precision-fit rubber boot. Engineered for the vehicle-side of the connection, this socket is designed for trucks and SUVs that operate in high-moisture or high-debris environments, ensuring your electric brakes and auxiliary circuits remain protected from the elements.

Rugged Construction & Dual Sealing Crafted from high-strength chrome-plated zinc die-cast, the 11-608 housing is built to withstand heavy impacts and resist the corrosive effects of road salt. The standout feature is the included rubber boot (Pollak 11-617), which slides over the rear of the socket to seal the wire entries against water, dirt, and road grime. This prevents terminal corrosion and electrical shorts before they can start.

Engineered for Professional Performance Inside the rugged metal shell, high-impact green ABS thermoplastic insulators house split-brass contacts. These contacts provide a secure "tension-fit" that maintains a consistent electrical flow even under heavy vibration. The socket also features a heavy-duty, spring-loaded cover with a positive-catch lid to protect the front terminals when your trailer is disconnected.

Key Features & Benefits:

• Rear Rubber Boot Included: Seals the back of the socket to protect wiring connections from moisture and dust.

• Die-Cast Zinc Housing: Chrome-plated for industrial-grade durability and corrosion resistance.

• 6-Pole Configuration: Provides circuits for ground, tail, stop, turn signals, and two auxiliary leads (Brakes/Battery).

• Split-Brass Contacts: Ensures maximum conductivity and a vibration-resistant connection (20 Amp rating).

• Spring-Loaded Lid: Keeps the interior clean and dry when not in use.

• Standard Mounting: 2-hole flange design for easy installation on bumpers or brackets.

Technical Specifications:

• Part Number: 11-608 (11-608P)

• Connection Type: 6-Pole Round Pin (Vehicle-Side Socket)

• Voltage: 12-24V DC

• Current Rating: 20 Amps

• Material: Chrome-Plated Zinc Die-Cast / Rubber

• Mounting: 2-Hole Flange (2.88" centers)

6-WAY CONNECTOR SOCKET WITH RUBBER BOOT

**Discontinued - Available While Supply Lasts
