Pollak 11-723 7-Way Round Pin Trailer Socket - Glass-Filled Nylon with Solid Brass Pins

Corrosion-Proof Performance for Heavy-Duty Fleets The Pollak 11-723 7-Way Round Pin Socket is an industrial-grade vehicle-side connector engineered for maximum durability and chemical resistance. Built to outperform traditional metal sockets in harsh conditions, this 7-pole connector is the standard for commercial trucking, agricultural machinery, and industrial trailers where road salt and moisture are constant threats.

Advanced Glass-Filled Nylon Construction The housing of the 11-723 is manufactured from high-impact glass-filled nylon. This advanced material is naturally 100% rust-proof, lightweight, and capable of withstanding extreme temperature fluctuations without cracking or degrading. Unlike die-cast zinc, this nylon housing will not pit or corrode, ensuring the socket remains functional and the lid operates smoothly for years of service.

Superior Electrical Integrity with Solid Pins Reliability is built into every pin. The 11-723 features solid brass pins for maximum durability and consistent electrical flow. To ensure long-term protection, the terminals are factory-packed with dielectric grease, providing a barrier against oxidation and moisture. Rated for 40 Amps continuous duty, this socket is designed to handle the high-current demands of modern trailers, including electric brakes and auxiliary power circuits.

Key Features & Benefits:

• Glass-Filled Nylon Housing: Maximum impact resistance and total immunity to rust and corrosion.

• Solid Brass Pins: Provides industrial-strength durability and superior electrical conductivity.

• 40A Continuous Duty: High-capacity power delivery for commercial 12V-24V systems.

• Factory-Applied Dielectric Grease: Protects internal terminals from moisture and road salt from day one.

• Spring-Loaded Protective Cover: Features a heavy-duty hinge and a positive-catch lid to keep the interior clean and dry.

• Standard SAE J560 Compliance: Fully interchangeable with all standard 7-way round pin trailer plugs.

Technical Specifications:

• Part Number: 11-723 (Bulk) / 11-723P (Packaged)

• Configuration: 7-Pole Round Pin (Vehicle-Side Socket)

• Pin Type: Solid Brass Pins

• Material: Black Glass-Filled Nylon

• Current Rating: 40 Amps Continuous Duty

• Voltage Rating: 6-28 Volts DC

• Mounting: 2-Hole Flange (2.93" centers)
