Pollak 11-998 7-Way Interlocking Mating Connector & 4-Foot Pigtail Wiring Harness

The Professional Solution for OEM Wiring Repair and Installation The Pollak 11-998 is a heavy-duty interlocking mating connector designed to provide a secure, weathertight connection for your vehicle's towing system. This kit is the industry standard for repairing damaged factory wiring or completing a professional-grade installation of an OEM 7-way socket. By mating perfectly with the back of the Pollak 11-893 or 11-916 sockets, it ensures your electrical connections remain protected from the elements.

Built for Durability and Conductivity Engineered with high-impact plastic and a 4-foot harness, the 11-998 is designed to thrive in the harsh environments under your truck. The connector features a specialized interlocking design that, when paired with a compatible socket, forms a sealed barrier against moisture, salt, and road grime. Inside, the 7-wire leads are color-coded to RVI standards for a straightforward, error-free hardwire installation.

Key Features:

• Universal OEM Fit: Specifically designed to mate with Pollak 11-893/11-893P and 11-916 sockets, as well as many factory-style plug-in connectors.

• 4-Foot Extended Reach: The 48-inch harness provides ample length for routing and securing wires away from heat sources and moving parts.

• RVI Color-Coded Leads: Simplifies the installation process with 7 industry-standard color-coded wires (Ground, Brakes, Tail/Running, Battery, Turn Signals, and Auxiliary).

• Protective Housing: Wires are encased in durable convoluted tubing to prevent abrasion and vibration damage.

• High Performance: Rated for 12V DC systems with a robust 30A/40A current capacity for heavy-duty towing applications.

Product Specifications:

• Brand: Pollak

• Part Number: 11-998 (also PK11998)

• Connection Style: 7-Pole Interlocking Mating Connector

• Harness Length: 4 Feet (48 Inches)

• Wire Gauge Breakdown: 10ga (White), 12ga (Blue, Black), 14ga (Red, Green, Brown, Yellow)

• Voltage/Current: 12V / 30-40 Amps

Wiring Reference (RVI Standard)

White: Ground (10 gauge), Blue: Electric Brakes (12 gauge), Black: Battery / Power (12 gauge), Red: Left Turn / Stop (14 gauge), Green: Right Turn / Stop (14 gauge), Brown: Running / Tail Lights (14 gauge), Yellow: Auxiliary / Back-up (14 gauge)
