Pollak 24-395 Momentary Start Switch – Heavy Duty Push Button with Red Weather Cap & 8-32 Threaded Studs

High-Visibility Reliability: Pollak 24-395 Weather-Sealed Momentary Start Switch

When your equipment operates in demanding conditions, you need a switch that is both easy to locate and built to last. The Pollak 24-395 is a professional-grade, momentary push-button switch designed for heavy-duty applications where moisture, dust, and vibration are constant challenges.

This switch stands out with its factory-installed red neoprene rubber boot. The vibrant red color ensures quick identification on a busy dashboard, while the "dust cap" design provides a superior seal against the elements. Inside, silver-plated contacts housed in a zinc die-cast body deliver consistent electrical performance for up to 50,000 cycles. The 8-32 threaded stud terminals offer a permanent, fail-safe connection that won't vibrate loose on the road or in the field.

Key Features:

• Weatherproof Red Boot: Includes the Pollak 25-352 red rubber boot nut, protecting the plunger from water, salt, and dirt while providing high visibility.

• Secure Threaded Terminals: Two 8-32 threaded studs (nuts included) ensure a rock-solid connection for ring terminal wiring.

• Heavy-Duty Construction: Rugged zinc die-cast housing with a high-impact plastic insulator designed for industrial longevity.

• Universal Voltage Support: High-capacity rating of 60 Amps at 12V DC and 40 Amps at 24V DC.

• Standard Mounting: Fits 5/8" diameter holes and panels up to 1/4" thick, making it a direct replacement for most heavy-duty start buttons.

Technical Specifications:

• Part Number: 24-395 (Replaces 24-395P)

• Circuitry: SPST Normally Off (Push-to-On)

• Rating: 60A @ 12V DC / 40A @ 24V DC

• Terminals: (2) 8-32 Threaded Studs

• Boot Color: Red (Neoprene Rubber)

• Mounting Stem: 5/8"-32 Thread, 5/8" Long

• Housing: Die-Cast Zinc
