Pollak 31-267 3-Position Ignition Switch - 4-Screw Terminals, D250 Keyed Alike

Professional-Grade Ignition Control for Heavy-Duty Equipment

The Pollak 31-267 Ignition Switch is a high-performance, 3-position starter switch engineered for the rigorous demands of the trucking, agricultural, and construction industries. This universal-type switch is housed in a rugged, one-piece zinc die-cast body, ensuring maximum durability and resistance to vibration in heavy-duty environments.

Reliable Performance with D250 Standardization Designed for fleet convenience, this model is Keyed Alike to the D250 code, making it a perfect replacement for Bobcat, Caterpillar, and other industrial machinery that standardizes on the D250 key. It features a momentary start function with a spring return to the "On/Accessory" position, providing smooth and reliable engine cranking every time.

Built to Outlast the Elements To prevent downtime caused by environmental failure, the 31-267 is equipped with an internal lip seal and a weather-resistant O-ring. These features protect the contact chamber from moisture, dust, and debris. Internally lubricated for life and featuring solid copper contacts, this switch offers superior electrical conductivity and a long service life.

Key Features:

• 3-Position Function: Off – On/Accessory – Start (Momentary).

• 4-Screw Terminals: Heavy-duty brass screw terminals provide secure, low-resistance connections.

• D250 Keyed Alike: Standardized keying for easier fleet management and operator convenience.

• Weatherproof Construction: Integrated lip seal and O-ring for protection against harsh weather and washdowns.

• Superior Materials: Zinc die-cast housing with a high-impact base and solid copper contacts.

Technical Specifications

• Part Number: 31-267 (or 31-267P for retail packaging)

• Switch Positions: 3 (Off - On/Acc - Start)

• Terminal Type: 4 Brass Screw Terminals

• Key Code: D250 (Keyed Alike)

• Voltage: 12V DC

• Amperage Rating: 30A @ 12V DC

• Housing: One-piece Zinc Die-Cast

• Mounting Hole Pattern: Pattern 5 (Standard Universal 1" Bushing)

• Common Applications: Bobcat Skid Steers, Excavators, Tractors, Commercial Trucks, and Industrial Generators.
