Pollak 31-285 3-Position Ignition Switch - 7-Blade Terminals, D250 Keyed Alike

Optimized Fleet Control for Heavy-Duty Equipment

The Pollak 31-285 Ignition Switch combines the convenience of a standardized keying system with the high-performance connectivity of a 7-blade terminal base. This 3-position switch is engineered for industrial and commercial applications where a "Start" position is required without the additional "Accessory" stage, providing a streamlined Off-On-Start sequence.

Standardized D250 Keying for Fleet Efficiency This model is Keyed Alike to the industry-standard D250 code. It is the ideal solution for fleet managers operating Bobcat, Caterpillar, or other heavy machinery who want the convenience of a single key across multiple units. The switch includes two D250 keys and is designed to fit standard 1-inch mounting holes.

Built for the Long Haul Constructed with a rugged zinc die-cast housing and a high-impact plastic base, the 31-285 is built to endure the vibration and mechanical stress of construction and agricultural environments. For protection against the elements, it features an internal lip seal and a weather-resistant O-ring, ensuring the solid copper contacts remain free from moisture and debris.

Key Features:

• 3-Position Function: Off – On – Start (Momentary).

• 7-Blade Terminals: High-capacity connectivity designed to fit Packard Connector #2984017.

• D250 Keyed Alike: Simplifies fleet management with standardized keying.

• Environmentally Sealed: Internal lip seal and O-ring provide superior weather resistance.

• Superior Conductivity: Solid copper contacts ensure reliable electrical performance and a long service life.

Technical Specifications

• Part Number: 31-285 (Pollak Aftermarket)

• Switch Positions: 3 (Off - On - Start)

• Terminal Type: 7 Blade Terminals

• Key Code: D250 (Keyed Alike)

• Housing Material: Die-Cast Zinc

• Base Material: High-Impact Plastic (Fits Packard Connector #2984017)

• Mounting Hole: Pattern 5 (Standard 1" Bushing)

• Current Rating (at 14V DC): * Ignition: 8A

• Start: 75A (Make) / 20A (Break)
