Pollak 31-607 4-Position Ignition Switch - Accessory-Off-On-Start - Heavy Duty Lever Actuated - 4 Stud Terminals

The Ultimate Heavy-Duty Control for Industrial Performance

The Pollak 31-607 Ignition Switch is a powerhouse of electrical control, engineered for heavy-duty trucks, construction machinery, and agricultural equipment. This 4-position switch replaces traditional keyed cylinders with a high-leverage manual handle, providing a tactile and "glove-friendly" solution for operators in demanding environments.

Full Range of Operation Designed to manage your vehicle's entire power cycle, the 31-607 features four distinct positions: Accessory - Off - On/Ignition - Start. The momentary "Start" position allows for easy engine cranking, while the "Accessory" position enables the use of electronics and lights without drawing power to the ignition system.

Rugged Construction & High Capacity Built to survive the toughest job sites, the 31-607 features a one-piece zinc die-cast housing and a high-impact base. It is equipped with four heavy-duty stud terminals for secure, vibration-resistant wiring connections. With a high amperage rating and solid copper contacts, this switch is designed to handle the electrical loads of modern industrial systems with ease.

Key Features:

• 4-Position Functionality: Accessory, Off, On (Ignition), and Momentary Start.

• Lever Handle Actuator: Easy to operate with gloves; ideal for open-cab equipment.

• 4 Stud Terminals: Provides a secure, high-conductivity connection for heavy-gauge wiring.

• Industrial Strength: One-piece zinc die-cast housing with high-impact internal base.

• Weather-Ready: Internally lubricated and sealed to resist moisture and corrosion.

Technical Specifications

• Part Number: 31-607 (Packaged version: 31-607P)

• Positions: 4 (Acc-Off-On-Start)

• Actuator: Lever Handle

• Terminals: 4 Stud Terminals

• Voltage: 6V - 24V DC

• Amperage Ratings: * Ignition: 30A @ 12V DC

• Accessory: 30A @ 12V DC

• Start: 10A @ 12V DC

• Mounting Stem: 3/4" Diameter, 15/32" Length

• Panel Thickness: Fits panels up to 1/4" thick
