Pollak 34-219 Heavy-Duty 50 Amp Toggle Switch - SPST ON-OFF, Black Handle

Extreme Power with a Stealth Look

The Pollak 34-219 Toggle Switch combines massive electrical capacity with a professional aesthetic. Rated for a powerful 50 Amps at 12V DC, this switch is designed to control high-draw systems such as hydraulic pumps, large cooling fans, and extensive auxiliary lighting arrays. Unlike standard chrome switches, the 34-219 features a non-glare black handle, making it a perfect fit for modern truck interiors or tactical equipment where a low-profile look is desired.

Engineered for Superior Conductivity

To handle high-amperage loads without failing, the 34-219 is built with silver-plated contacts. Silver provides the highest level of electrical conductivity and superior heat dissipation, significantly reducing the risk of contact pitting or arcing. The rugged die-cast housing and high-impact plastic base ensure this switch can withstand the heavy vibration and mechanical stress found in vocational trucks and construction machinery.

Secure Mechanical Installation

This Single Pole, Single Throw (SPST) switch provides a smooth, positive "snap" action for clear ON-OFF control. It is equipped with two #10-32 threaded screw terminals, allowing for a high-torque, vibration-resistant connection that stays secure even in the most demanding environments.

Technical Specifications:

• Part Number: 34-219 (Retail Pack: 34-219P)

• Function: ON-OFF (SPST - Single Pole, Single Throw)

• Handle Style: Standard Black Finish Bat Handle

• Current Rating:

• 50 Amps at 12V DC

• 25 Amps at 24V DC

• Contacts: High-Conductivity Silver-Plated

• Terminals: (2) #10-32 Threaded Brass Screw Terminals

• Mounting: Fits standard 1/2" diameter mounting holes

• Mounting Stem: 15/32" - 32 thread; includes mounting hardware (nuts and lock washer)

• Life Cycle: Rated for up to 25,000 cycles at full load
