Pollak 34-222 Heavy-Duty Toggle Switch – 50 Amp, SPDT, On-Off-On, Black Handle

Industrial-Grade Reliability for High-Current Power Control

The Pollak 34-222 Heavy-Duty Toggle Switch is a robust electrical solution built to handle the rigorous demands of heavy-duty trucks, marine vessels, and industrial machinery. Engineered for high-current applications, this Single Pole, Double Throw (SPDT) switch provides dependable On-Off-On functionality, allowing you to control two separate circuits from a single central location.

Engineered for Durability:

Unlike standard consumer-grade switches, the Pollak 34-222 features a rugged die-cast body and a glass-filled nylon slide designed to resist vibration and mechanical wear. The oversized internal copper contacts and copper contact bridge ensure maximum conductivity and a long service life, even under constant 50 Amp loads.

Key Features & Construction:

• Three-Position Control: (On)-Off-(On) circuitry allows for versatile operation of auxiliary lights, motors, or specialized equipment.

• Ergonomic Black Handle: Features a custom-designed 1-inch black handle for a professional look and easy tactile identification.

• Heavy-Duty Ratings: Certified for 50 Amps at 12V DC, providing the power needed for high-draw electrical systems.

• Secure Wiring: Equipped with three #8-32 screw terminals mounted on a heat-resistant laminated bakelite base for secure, vibration-proof connections.

• Precision Mounting: Standard 15/32" diameter mounting stem with a nickel-plated hex nut for easy installation in existing dash or control panels.

Whether you're maintaining a fleet or building a custom electrical rig, the Pollak 34-222 offers the precision and strength required for professional-grade performance.

Technical Specifications:

• Part Number: 34-222 (also referenced as 34-222P or 34-222EP)

• Circuitry: SPDT (Single Pole, Double Throw)

• Function: On - Off - On

• Rating: 50 Amps at 12V DC

• Handle Type: 1" Standard Black Handle

• Terminals: (3) #8-32 Screw Terminals

• Construction: Die-cast body with Copper Contacts
