Pollak 34-223 Heavy-Duty Toggle Switch – 50 Amp, SPDT, (On)-Off-(On) Momentary, Black Handle

Heavy-Duty Momentary Control for High-Current Performance

The Pollak 34-223 Heavy-Duty Toggle Switch is a high-performance electrical component designed for the most demanding environments. Engineered with a 50 Amp rating, this Single Pole, Double Throw (SPDT) switch is built to handle heavy electrical loads in trucking, construction, and marine applications where temporary circuit activation is required.

Designed for Precision and Durability: The 34-223 features a (Momentary On)-Off-(Momentary On) configuration, making it the ideal choice for operating winches, lift gates, snow plows, and auxiliary equipment that requires precise, temporary power. Its rugged die-cast body and glass-filled nylon slide ensure that the switch can withstand high-vibration environments and repeated industrial use.

Key Features & Construction:

• Momentary Action: Double-sided momentary functionality ensures power is only delivered while the lever is held, providing enhanced safety and control for motor-driven accessories.

• Industrial Power Rating: Specifically designed to carry up to 50 Amps at 12V DC (25 Amps at 24V DC), handling high-current draws without overheating.

• Premium Contacts: Oversized internal copper contacts and a copper contact bridge provide maximum conductivity and a significantly longer service life than standard switches.

• Ergonomic Black Handle: Equipped with a standard 1-inch black handle for a clean, professional look and easy tactile operation in any control panel.

• Superior Terminals: Features three #8-32 screw terminals mounted on a heat-resistant laminated bakelite base for secure, vibration-proof wiring.

Technical Specifications:

• Part Number: 34-223

• Circuitry: SPDT (Single Pole, Double Throw)

• Function: (Momentary On) - Off - (Momentary On)

• Rating: 50 Amps at 12V DC; 25 Amps at 24V DC

• Handle Type: 1" Standard Black Handle

• Mounting Stem: 15/32" Diameter, 15/32" Length

• Terminals: (3) #8-32 Screw Terminals

• Body Material: Rugged Die-Cast Housing
