Pollak 34-230 Sealed Illuminated Rocker Switch – 20 Amp, SPST, On-Off, White Pilot Light

Enhanced Visibility and Weatherproof Reliability

The Pollak 34-230 Sealed Illuminated Rocker Switch is a high-performance electrical control designed for professional-grade reliability in automotive, trucking, marine, and RV industries. Featuring a crisp White Pilot Light, this switch provides immediate visual confirmation of circuit status, making it ideal for low-light environments and daytime signaling alike.

Engineered for Harsh Environments:

Part of Pollak’s premium sealed series, the 34-230 is built to withstand dust, moisture, and vibration. Its rugged black nylon housing and bezel are designed for long-term durability in dashboards, control panels, and exposed marine consoles.

Key Features & Construction:

• Sealed Protection: Designed with enhanced protection against environmental contaminants, ensuring consistent performance in demanding conditions.

• Illuminated White Lens: Features a bright white pilot light/lens with an internal LED/bulb that activates in the "On" position for easy identification.

• Efficient Circuitry: Single Pole, Single Throw (SPST) On-Off function provides simple, reliable control for auxiliary lights, fans, or pumps.

• 4-Blade Terminal Configuration: Equipped with four .250" wide brass blade terminals for secure, high-conductivity connections.

• Snap-In Installation: Universal snap-in design fits standard .830" x 1.450" panel cutouts, accommodating panel thicknesses from .093" to .187".

• Industrial Rating: Rated for 20 Amps at 12V DC, providing the capacity needed for most vehicle electrical accessories.

Technical Specifications:

• Part Number: 34-230 (also referenced as 34-230P)

• Circuitry: SPST (Single Pole, Single Throw)

• Function: On - Off

• Illumination: White Pilot Light (White Lens)

• Rating: 20 Amps @ 12V DC

• Terminals: (4) .250" Brass Blade Terminals

• Body Material: Black Nylon Housing and Bezel

• Cutout Dimensions: 0.830" x 1.450"
