Pollak 34-236 Sealed Momentary Rocker Switch | SPDT (On)-Off-(On), White Pilot Light

Precision Control with Momentary Action

The Pollak 34-236 Rocker Switch is engineered for applications requiring temporary power bursts or precise incremental adjustments. Featuring a Momentary On – Off – Momentary On configuration, this switch stays in the "On" position only while pressed, making it the perfect choice for winches, power windows, hatches, or any dual-directional equipment that requires a "return to center" safety feature.

Built for the Long Haul

Part of Pollak’s "Weather-Beater" series, the 34-236 is a fully sealed switch designed to thrive in high-moisture and high-debris environments. Whether it’s mounted in a heavy truck dashboard or a marine control panel, the high-impact nylon bezel and housing provide a rugged barrier against the elements.

Key Technical Specifications:

• Part Number: 34-236 (Pollak Aftermarket)

• Circuitry: SPDT (Single Pole Double Throw)

• Action: Momentary On - Off - Momentary On (Spring return to center)

• Illumination: Integrated White Pilot Light (LED) for status visibility

• Terminals: 5 Blade Terminals (.250" Quick Connect)

• Electrical Rating: Heavy-duty 20 Amps at 12VDC (6-24V range)

• Construction: Sealed housing with silver contacts for maximum conductivity

• Mounting: Snap-in mounting designed for standard 0.830" x 1.450" cutouts
