Pollak 34-239 Sealed Momentary Rocker Switch | DPDT (On)-Off-(On), White Pilot Light, 10 Blade

Ultimate Control for Complex Systems

The Pollak 34-239 Rocker Switch is a heavy-duty, multi-functional component designed for applications requiring temporary power to two separate circuits. With its DPDT (Double Pole Double Throw) configuration and Momentary On-Off-Momentary On action, this switch provides a spring-return-to-center function. It is the professional choice for controlling dual-directional equipment like power liftgates, winches, slide-outs, and specialized hydraulic systems.

Engineered for Survival

As a member of Pollak's "Weather-Beater" series, the 34-239 is fully sealed to withstand the harshest environments. Whether exposed to road salt on a heavy truck or sea spray on a marine vessel, the moisture and dust-resistant housing ensures long-term reliability. The integrated White Pilot Light (LED) offers a clean, high-visibility status indicator, ensuring the operator can find the control in any lighting condition.

Key Technical Specifications:

• Part Number: 34-239 (Pollak Aftermarket)

• Circuitry: DPDT (Double Pole Double Throw)

• Switch Action: Momentary On - Off - Momentary On (Spring Return)

• Illumination: High-Visibility White LED Pilot Light

• Terminal Design: 10 Blade Terminals (.250" Quick Connect)

• Electrical Rating: Heavy-duty 20 Amps at 12VDC

• Protection: Sealed construction for superior weather resistance

• Mounting: Snap-in design for standard 0.830" x 1.450" panel cutouts

• Hardware: Silver contacts for maximum conductivity and reduced heat
