Pollak 34-305 Illuminated Rocker Switch | SPST On-Off | Red Pilot Light | 20A 12VDC | 3-Screw Terminals

Enhanced Visibility and Control

The Pollak 34-305 Rocker Switch is a high-performance electrical solution featuring a built-in Red Pilot Light for immediate visual status at a glance. Designed for automotive, heavy-duty truck, marine, and RV applications, this Single Pole-Single Throw (SPST) switch provides dependable On-Off control for auxiliary lighting, safety equipment, and power accessories.

Rugged Construction for Professional Use

Built with a durable black nylon bezel and housing, the 34-305 is engineered to withstand demanding environments. The red illuminated lens is integrated directly into the actuator, lighting up when the switch is in the "On" position to prevent accidental battery drain and improve safety in low-light conditions.

Fast, Secure Installation This switch features a universal snap-in design that fits standard .830" x 1.450" panel cutouts. The three-screw terminal configuration (Power, Load, and Ground for the light) ensures a secure, vibration-resistant electrical connection that won’t shake loose on the road or water.

Key Features:

• Illuminated Red Pilot Light: Provides clear visual confirmation when the circuit is active.

• Heavy-Duty Rating: Built to handle 20 Amps at 12VDC.

• 3-Screw Terminals: Features brass screw terminals for maximum conductivity and secure wiring.

• Universal Fit: Ideal for trucks, buses, tractors, and marine vessels.

• Precision Mounting: Easy snap-in installation for panel thicknesses of .093", .125", and .187".

Specifications:

• Part Number: 34-305 (Packaged version: 34-305P)

• Circuitry: SPST (Single Pole-Single Throw)

• Positions: 2 (On-Off)

• Illumination: Red Pilot Light (LED/Bulb)

• Rating: 20 Amps @ 12VDC

• Termination: 3 Brass Screw Terminals

• Material: Impact-resistant Nylon (Housing & Bezel)

• Panel Cutout: .830" x 1.450"
