Pollak 34-307 Illuminated Rocker Switch | SPST On-Off | Amber Pilot Light | 20A 12VDC | 3-Screw Terminals

Reliable Status Monitoring with Amber Illumination

The Pollak 34-307 Rocker Switch is a professional-grade electrical component designed to provide clear, color-coded feedback for your vehicle's systems. Featuring a built-in Amber Pilot Light, this switch is the industry standard for indicating active auxiliary power, warning lights, or specialized equipment in trucks, RVs, and marine applications.

Built for the Long Haul

Constructed with a high-impact black nylon housing and bezel, the 34-307 is engineered to endure the vibrations and environmental demands of heavy-duty trucking. The amber lens is integrated directly into the rocker actuator, providing a sleek, low-profile look that glows brightly when the circuit is switched to "On."

Secure and Simple Installation Designed for a universal fit, this switch snaps easily into standard .830" x 1.450" panel cutouts. It features three brass screw terminals (Power, Load, and Ground), ensuring a high-conductivity, mechanical connection that won't vibrate loose—even on the roughest roads.

Key Features:

• Amber Indicator Light: Provides clear visual confirmation of circuit status.

• High Current Rating: Handles up to 20 Amps at 12VDC safely.

• Universal Snap-In Mounting: Fits panel thicknesses of .093", .125", and .187".

• Heavy-Duty Terminals: 3 brass screw terminals for secure wiring.

• Rugged Design: Durable nylon construction resists impact and wear.

Specifications:

• Part Number: 34-307 (Retail Pack: 34-307P)

• Circuitry: SPST (Single Pole-Single Throw)

• Function: On-Off

• Illumination: Amber Pilot Light (Integral Lens)

• Rating: 20 Amps @ 12VDC

• Termination: 3 Brass Screw Terminals

• Panel Cutout: .830" x 1.450"

• Body Material: Black Nylon
