Pollak 34-570Q Momentary Toggle Switch (On)-Off | SPST 20A 12VDC | Quick Connect Blade Terminals

The Pollak 34-570Q is a high-performance, medium-duty toggle switch designed for applications that require temporary power. Unlike the standard 34-570, this "Q" version features .250” Quick Connect blade terminals, making it the ideal choice for fast, secure installations in modern wiring harnesses without the need for screw-down connections.

This Single Pole, Single Throw (SPST) switch is engineered for durability in demanding environments. It features a "Momentary On-Off" action—perfect for horns, starters, winches, or any function where you need power only while your finger is on the switch. Built with copper alloy conductors, it ensures maximum conductivity and minimal voltage drop.

Key Features:

• Quick Connect Terminals: Equipped with two .250” male blade terminals for rapid "plug and play" installation.

• Momentary Action: Spring-loaded (On)-Off circuitry returns the switch to the "Off" position automatically when released.

• Rugged Construction: Features a zinc die-cast housing and a classic chrome-plated standard handle (11/16") for a professional, long-lasting finish.

• Reliable Performance: Rated for 20 Amps at 12VDC, suitable for a wide range of automotive, truck, and marine electrical systems.

• Weatherproof Ready: Designed for medium-duty use in trucks, buses, off-road vehicles, and construction equipment.

Technical Specifications:

• Part Number: 34-570Q (also available as 34-570QP in retail packaging)

• Circuitry: SPST (Single Pole, Single Throw)

• Switch Action: Momentary On - Off

• Rating: 20 Amps @ 12VDC / 10 Amps @ 24VDC

• Terminals: 2 Blade Terminals (.250" Quick Connect)

• Handle Type: Standard Toggle (Chrome Finish)

• Handle Length: 11/16 inch

• Mounting: Fits standard 15/32" diameter mounting holes
