Pollak 34-571LQ Long Handle Toggle Switch On-Off | SPST 20A 12VDC | .250” Quick Connect Terminals

The Pollak 34-571LQ combines the accessibility of an extended lever with the speed of modern electrical termination. This heavy-duty Single Pole, Single Throw (SPST) "On-Off" switch features a 1 1/2" long handle, providing maximum leverage and visibility for operators who need quick, easy access to controls—even while wearing heavy work gloves.

Unlike standard screw-terminal models, the 34-571LQ is designed with .250” Quick Connect blade terminals. This allows for a fast, snap-in installation that is ideal for modern wiring harnesses and fleet maintenance where downtime must be kept to a minimum. Built with a rugged zinc die-cast housing and a chrome-plated handle, this switch is a staple for heavy trucks, agricultural machinery, and industrial equipment.

Key Features:

• Extended Reach: 1 1/2" long chrome handle for superior ergonomics and glove-friendly operation.

• Rapid Installation: Two .250” male blade (Quick Connect) terminals for secure, solderless connections.

• High-Amp Reliability: Rated for 20 Amps at 12VDC, making it suitable for auxiliary lighting, motors, and fans.

• Heavy-Duty Build: Zinc die-cast body with copper alloy conductors for long-lasting performance in vibration-heavy environments.

• Universal Fit: Standard 15/32" mounting stem fits most existing dashboard and control panel holes.

Technical Specifications:

• Part Number: 34-571LQ

• Circuitry: SPST (Single Pole, Single Throw)

• Switch Action: On - Off (Maintained)

• Rating: 20 Amps @ 12VDC / 10 Amps @ 24VDC

• Terminals: 2 Blade Terminals (.250" Quick Connect)

• Handle Type: Long Toggle (Chrome Finish)

• Handle Length: 1 1/2 inch

• Mounting Stem: 15/32" Diameter, 15/32" Long
