Pollak 34-571Q Toggle Switch On-Off | SPST 20A 12VDC | .250” Quick Connect Blade Terminals

The Pollak 34-571Q is a professional-grade Single Pole, Single Throw (SPST) toggle switch engineered for high-efficiency electrical control. This "On-Off" maintained switch is a favorite among fleet mechanics and upfitters because it replaces traditional screw terminals with .250” Quick Connect blade terminals, significantly reducing installation time and simplifying repairs.

Built to endure the vibration and environmental stress of heavy-duty trucking, this switch features a robust zinc die-cast housing and a classic chrome-plated handle. Whether you are controlling interior cabin lights, auxiliary fans, or peripheral electronics, the 34-571Q delivers a crisp, positive detent action and long-lasting electrical reliability.

Key Features:

• Fast Termination: Features two .250” male blade terminals for easy "push-on" connection with standard female spade connectors.

• Standard On-Off Action: Maintained two-position circuitry (On-Off) for consistent power control.

• Heavy-Duty Rating: Built to handle 20 Amps at 12VDC or 10 Amps at 24VDC.

• Rugged Aesthetics: Equipped with an 11/16" standard chrome-plated handle for a clean, professional look on any dashboard.

• Superior Conductivity: Internal copper alloy conductors ensure low resistance and heat dissipation under load.

Technical Specifications:

• Part Number: 34-571Q (Bulk) / 34-571QP (Retail)

• Circuitry: SPST (Single Pole, Single Throw)

• Action: On - Off (Maintained)

• Electrical Rating: 20 Amps @ 12VDC

• Terminals: 2 Blade Terminals (.250" Quick Connect)

• Handle Type: Standard Toggle (Chrome Finish)

• Handle Length: 11/16 inch

• Mounting Stem: 15/32" Diameter, 15/32" Long
