Pollak 34-576Q Heavy-Duty Toggle Switch – On-On DPDT with 6 Quick-Connect Blade Terminals (20 Amp)

High-Efficiency Dual-Circuit Switching

The Pollak 34-576Q is a high-performance Double Pole Double Throw (DPDT) toggle switch engineered for rapid installation and long-term reliability. Featuring an On-On configuration and 6 Quick-Connect (QC) blade terminals, this switch allows you to toggle power seamlessly between two independent circuits. The .250” (6.4mm) blade terminals eliminate the need for manual wire wrapping, making it the perfect choice for high-volume fleet maintenance and streamlined electrical builds.

Rugged Performance for Heavy-Duty Systems Designed to handle the demands of commercial trucks, agricultural machinery, and industrial equipment, the 34-576Q is built with a die-cast housing and a high-impact glass-filled nylon slide. These materials ensure the switch can withstand high-vibration environments while maintaining consistent electrical contact. With a 20 Amp rating at 12VDC, it provides robust power handling for various accessories and motor-reversing applications.

Key Features:

• Circuitry: On-On (DPDT – 6 Terminals)

• Rating: 20 Amps at 12VDC (also suitable for 6V to 24V applications)

• Terminal Type: 6 x .250" (6.4mm) Quick-Connect Blade Terminals

• Handle Style: Standard 11/16" Chrome-plated handle for easy operation

• Secure Mounting: 15/32" diameter mounting stem; fits standard 1/2" holes

• Included Hardware: 1 Nickel-plated hex nut and 1 aluminum knurled face nut

• Industry Reliability: Engineered by Pollak, an OEM leader in heavy-duty vehicle electronics
