Circuitry: On-Off-On (DPDT – 6 Terminals)
-
Electrical Rating: 20 Amps at 12VDC (Compatible with 6-24V systems)
-
Action: 3-Position maintained toggle (stays in the selected position)
-
Terminal Type: 6 x #8-32 Screw Terminals for secure wiring
-
Durable Design: Die-cast body with oversized copper contacts for low resistive loss
-
Mounting: Fits standard 1/2" diameter mounting holes; includes mounting hardware (hex nut and knurled face nut)
-
Applications: Ideal for Freightliner, Kenworth, and PACCAR trucks, as well as marine and industrial use
SKU
34-577
Manufactures SKU
POLLAK 34-577
Pollak 34-577 Heavy-Duty Toggle Switch – On-Off-On DPDT with 6 Screw Terminals (20 Amp)
$7.66
EA
Ultimate Control for Complex Electrical Systems
The Pollak 34-577 is a professional-grade Double Pole Double Throw (DPDT) toggle switch designed for multi-function circuit management. Featuring an On-Off-On configuration, this switch allows you to toggle between two separate functions while providing a solid center "Off" position. This makes it an essential choice for dual-accessory systems, such as switching between different sets of auxiliary lights, managing two-speed motors, or controlling directional equipment in heavy-duty trucks and off-road vehicles.
Engineered for Rugged Environments Built to meet rigorous OEM standards, the 34-577 is constructed with a die-cast housing and a high-impact Bakelite base. The 6 screw terminals (#8-32) are securely riveted to prevent loosening from road vibration, ensuring a consistent electrical connection in even the harshest commercial environments. The 11/16" standard chrome-plated handle offers a reliable grip and tactile feedback for confident operation.
PICTURE FOR REFERENCE, IMAGE MAY NOT BE EXACT. *
Features & Benefits
Current Amp
20
Number of Terminal Connections
6
Product Type
Double Pole, Double Throw
Voltage
6-24V DC (20 Amps at 12V DC)
Shipping Weight (lbs)
0.100000
