Pollak 34-577Q Heavy-Duty Toggle Switch – On-Off-On DPDT with 6 Quick-Connect Blade Terminals (20 Amp)

Versatile Dual-Circuit Control with Rapid Installation

The Pollak 34-577Q is a high-performance Double Pole Double Throw (DPDT) toggle switch designed for multi-function electrical systems in heavy-duty trucks, marine vessels, and industrial equipment. Featuring an On-Off-On configuration and 6 Quick-Connect (QC) blade terminals, this switch allows for seamless toggling between two independent circuits while providing a reliable center "Off" position.

Speed and Security Equipped with .250" (6.4mm) male blade terminals, the 34-577Q is built for efficiency. These terminals allow for fast, solderless "snap-on" connections, making it the ideal choice for high-volume fleet maintenance or tight dashboard installs where screw-tightening is difficult.

Proven Durability Like all Pollak heavy-duty switches, the 34-577Q is engineered for long-term survival in high-vibration environments. It features a rugged die-cast housing, a glass-filled nylon slide, and copper alloy conductors that ensure superior electrical conductivity with minimal resistive loss.

Key Features:

• Circuitry: On-Off-On (DPDT – 6 Terminals)

• Rating: 20 Amps @ 12VDC (Universal 6V to 24V compatibility)

• Terminal Type: 6 x .250" Quick-Connect Male Blades

• Protection: Weather-resistant plastic coating with an O-ring seal in the stem to guard against moisture and dust.

• Hardware: Includes 1 nickel-plated hex nut and 1 aluminum knurled face nut.

• Standard Fit: 15/32" diameter mounting stem fits standard 1/2" holes.

• Handle Style: 11/16" standard chrome-plated handle for a classic look and durable grip.
