Pollak 34-578 Heavy-Duty Toggle Switch – (On)-Off-On DPDT with 6 Screw Terminals (20 Amp)

Specialized Control with Single-Sided Momentary Action

The Pollak 34-578 is a unique Double Pole Double Throw (DPDT) switch designed for specific industrial and automotive tasks. It features a (On)-Off-On configuration, providing one Momentary-On position that springs back to center, and one Maintained-On position that stays locked in place. This setup is ideal for equipment requiring both a constant-run mode and a temporary "jog" or "override" function.

Heavy-Duty Fleet Reliability Built to the rigorous standards expected of Pollak aftermarket parts, the 34-578 is designed for longevity in high-vibration environments. The 6 screw terminals (#8-32) are riveted to a durable Bakelite base, ensuring your wiring stays secure even on the roughest roads.

Key Features:

• Circuitry: (On)-Off-On (DPDT – 6 Terminals)

• Action: 1 Momentary Position, 1 Center-Off, 1 Maintained Position

• Electrical Rating: 20 Amps at 12VDC

• Rugged Build: Die-cast housing with a chrome-plated 11/16" standard handle.

• Secure Mounting: 15/32" diameter mounting stem fits standard 1/2" holes.

• Hardware Included: Includes 1 nickel-plated hex nut and 1 aluminum knurled face nut.
