Pollak 34-591LQ Toggle Switch – Momentary (On)-Off-(On) DPDT – 4 QC Blade Terminals, Long Handle

Heavy-Duty Performance for Demanding Environments

The Pollak 34-591LQ Toggle Switch is a premium, medium-duty solution designed for reliable performance in automotive, truck, and industrial applications. Built with a rugged zinc die-cast housing and copper alloy conductors, this switch ensures superior electrical conductivity and long-term durability against the vibration and wear common in commercial vehicles.

Momentary (On)-Off-(On) Functionality This switch features DPDT (Double Pole, Double Throw) circuitry with a momentary action. The "(On)" positions mean the switch will automatically return to the center "Off" position once released—making it ideal for applications like motor reversing, lift gates, winches, and slide-outs.

Key Features:

• Long Handle Design: Features a 1.5-inch chrome-plated long handle for easy operation, even while wearing gloves.

• 4 QC Blade Terminals: Equipped with 1/4" Quick Connect (QC) blade terminals for fast, secure wiring.

• Weather Resistant: Designed with a plastic coating and O-ring seal in the stem to protect internal components from moisture and dust.

• Tested Reliability: 100% factory tested for mechanical and electrical switching performance to ensure safety and longevity.

Technical Specifications:

• Part Number: 34-591LQ

• Circuitry: (On)-Off-(On) / Momentary On - Off - Momentary On

• Configuration: DPDT (4 Terminals)

• Rating: 20 Amps @ 12V DC

• Voltage Range: 6V to 24V DC

• Handle Length: 1.5" (Long Handle)

• Handle Finish: Chrome

• Mounting: Through-hole mounting for standard panels
