Pollak 34-592 Toggle Switch – DPDT On-On, 6 Screw Terminals, Heavy Duty Reversing Switch

Reliable Control for Heavy-Duty Applications

The Pollak 34-592 Toggle Switch is a high-performance Double Pole, Double Throw (DPDT) switch engineered for the most demanding automotive and industrial environments. Whether you are managing complex lighting setups or motor-driven equipment, this switch provides the durability and precision Pollak is known for.

Versatile DPDT On-On Functionality Featuring On-On circuitry, this switch is designed to toggle between two active circuits without an "Off" position in the middle. With its 6-screw terminal configuration, it is the industry standard for motor reversing applications (such as winches or lift gates) and complex multi-circuit switching in trucks, trailers, and off-road vehicles.

Key Features:

• Heavy-Duty Construction: Built with a rugged zinc die-cast housing and a glass-filled nylon slide for long-lasting mechanical life.

• Superior Conductivity: Equipped with oversized internal copper contacts and brass terminals to ensure maximum electrical efficiency and minimal voltage drop.

• Secure Connections: Features 6 #8-32 screw terminals with two jumper blades included, providing a vibration-proof connection that is ideal for heavy-duty commercial use.

• Standard Mounting: Designed with a 15/32” diameter mounting bushing, making it a direct fit for most standard control panels.

Technical Specifications:

• Part Number: 34-592 (Packaged as 34-592P)

• Circuitry: DPDT On-On (Reversing and Non-Reversing)

• Current Rating: 20 Amps @ 12V DC

• Voltage Range: Compatible with 6V to 24V DC systems

• Terminal Type: 6 Screw Terminals

• Handle Type: Standard Toggle Handle (15/32" length)

• Bushing Length: 15/32"

• Industry Standards: Manufactured by an ISO9001/QS9000 certified facility.
