Pollak 34-593LQ Toggle Switch – DPDT On-Off-On, Long Handle, 6 QC Blade Terminals

Heavy-Duty Control with Extended Reach

The Pollak 34-593LQ Toggle Switch is a high-performance Double Pole, Double Throw (DPDT) solution designed for the rigorous demands of the heavy-duty truck, automotive, and industrial sectors. This switch provides a reliable, mechanical interface for managing dual-circuit systems with precision and ease.

Engineered for Ease of Use The "LQ" designation signifies the 1.5-inch long chrome handle, which provides increased leverage and visibility. This makes the 34-593LQ an ideal choice for dash panels where switches need to be operated while wearing gloves or in high-vibration environments.

Key Features:

• 3-Position On-Off-On Circuitry: Allows for the independent control of two different circuits with a definitive center-off position.

• 6 Quick-Connect (QC) Blade Terminals: Features .250” male blade terminals for rapid, secure, and solderless wiring—saving time during installation and maintenance.

• Rugged Construction: Built with a zinc die-cast housing and copper alloy conductors to ensure maximum electrical conductivity and low resistive loss.

• Weather Protected: Equipped with a specialized O-ring seal in the stem and a weather-resistant plastic coating to guard against moisture, dust, and road salt.

• Independently Tested: Every Pollak switch is 100% factory tested to verify mechanical and electrical switching performance.

Technical Specifications:

• Part Number: 34-593LQ (also available as 34-593LQP / 34-593LQV)

• Circuitry: DPDT On-Off-On (maintained)

• Current Rating: 20 Amps @ 12V DC

• Voltage Compatibility: 6V to 24V DC

• Handle Type: 1.5" Long Chrome Handle

• Terminal Type: 6 Blade (Quick Connect)

• Mounting Stem: 15/32" Diameter, 15/32" Length
