Pollak 34-596 Toggle Switch – SPDT On-Off-(On) Momentary, 3 Screw Terminals, Medium Duty

Reliable Momentary Control for Professional Rigging

The Pollak 34-596 Toggle Switch is a high-quality Single Pole, Double Throw (SPDT) switch engineered for precision and durability in the automotive and heavy-duty truck markets. This "Medium Duty" series switch is a staple for technicians who require a dependable interface for multi-stage electrical systems.

On-Off-(On) Momentary Functionality This switch features a unique On-Off-(On) circuitry. While the first "On" and "Off" positions are maintained (locking), the final "(On)" position is momentary. This means the switch will automatically spring back to the "Off" center position when released from the momentary side—making it perfect for auxiliary functions like glow plugs, primers, or temporary accessory activation.

Key Features:

• 3-Screw Terminal Design: Equipped with three #8-32 plated combination head screw terminals for a secure, vibration-proof connection that won't shake loose on the road.

• Rugged Construction: Built with a zinc die-cast housing and copper alloy conductors to ensure superior electrical conductivity and minimal resistive loss.

• Weather-Resistant Seal: Features a protective plastic coating and a specialized O-ring seal in the stem to keep out moisture, dust, and road grime.

• Classic Styling: Finished with a standard-length chrome-plated handle for a clean, professional look on any dashboard or control panel.

• Proven Durability: 100% factory tested to verify both mechanical and electrical switching performance under load.

Technical Specifications:

• Part Number: 34-596 (Bulk) / 34-596P (Packaged)

• Circuitry: SPDT On-Off-(On) [Maintained-Off-Momentary]

• Rating: 20 Amps @ 12V DC (Universal 6V-24V compatibility)

• Terminals: 3 Screw Terminals (#8-32)

• Handle: 1" Standard Chrome Handle

• Mounting: Through-hole mounting; fits standard 15/32" diameter holes.
