Pollak 35-306 High-Capacity Push-Pull Switch – 75 Amp On-Off, 2 Screw Terminals, Extra Heavy Duty

Professional Grade High-Current Control

The Pollak 35-306 is engineered for applications that demand significantly higher current capacity than a standard dash switch can provide. Rated for a massive 75 Amps at 12V DC, this extra heavy-duty Push-Pull switch is the industry standard for controlling high-draw equipment without the immediate need for an external relay in many configurations.

Built for Extreme Conditions

Designed for the rigors of heavy trucking, construction, and agricultural machinery, the 35-306 features a robust zinc die-cast housing and a classic silver-finished knob. The internal silver-plated contacts ensure maximum conductivity and longevity, even under constant high-load switching.

Key Features:

• Extra High Capacity: Rated at 75 Amps (12V DC), making it one of the most powerful manual push-pull switches available.

• Simple SPST On-Off Circuitry: Traditional pull-to-on, push-to-off operation for intuitive control.

• Secure 2-Screw Terminals: Equipped with two heavy-duty #10-32 screw terminals to accommodate larger gauge wiring required for high-amp loads.

• Universal Mounting: Fits 5/8" diameter mounting holes, providing a secure fit in heavy-duty dash panels.

Technical Specifications:

• Part Number: 35-306 (Packaged as 35-306P)

• Circuitry: SPST On-Off

• Current Rating: 75 Amps @ 12V DC; 40 Amps @ 24V DC

• Terminals: 2 Screw Terminals (#10-32)

• Knob Material: Chrome Coated

• Mounting Stem: 5/8" Diameter, 15/32" Long

• Housing Material: Zinc Die-Cast
