Pollak 35-320 Axle Shift Control Switch – Heavy-Duty Push-Pull On-Off – Two-Speed Axle Selector

Precision Control for Two-Speed Axles

The Pollak 35-320 is a specialized, heavy-duty push-pull switch specifically engineered for axle shift control in medium and heavy-duty trucks. Built to manage the demands of two-speed axle systems, this switch provides the reliable, tactile interface necessary for shifting gear ratios under various load conditions.

Built for the Long Haul

Constructed with a rugged zinc die-cast housing, the 35-320 is designed to withstand the high-vibration environment of a truck cab. To ensure driver safety and ease of use, it features a high-visibility red plastic knob, allowing for immediate identification among other dash controls.

Key Features:

• Specific Application: Primarily used for two-speed axle shifting (High/Low range).

• High-Visibility Interface: Equipped with a bold red knob for quick identification in the cabin.

• Rugged Construction: Zinc die-cast body provides superior durability and impact resistance compared to standard plastic switches.

• Secure Electrical Connection: Features two #8-32 combination head screw terminals for a permanent, vibration-proof connection.

• Reliable Conductivity: Internal copper alloy conductors ensure low resistance and consistent electrical performance.

• Versatile Voltage: Rated for 15 Amps at 12V DC, compatible with 6V through 28V DC systems.

Technical Specifications:

• Part Number: 35-320 (Packaged as 35-320P)

• Circuitry: SPST On-Off

• Current Rating: 15 Amps @ 12V DC

• Terminals: 2 Terminal Male Connector

• Knob Color: Red

• Mounting Stem: 1/2" Diameter, 5/8" Long

• Housing Material: Zinc Die-Cast
