Pollak 51-916 Master Disconnect Switch with Removable Key – 180A, Weatherproof

The Pollak 51-916 Master Disconnect Switch offers a unique combination of electrical safety and vehicle security. Unlike standard lever-operated switches, the 51-916 features a removable key that allows you to lock the battery in the "Off" position. This makes it an essential tool for preventing unauthorized vehicle use, deterring theft, and ensuring the battery doesn't drain during long periods of inactivity.

Built to withstand the rigors of heavy-duty applications, this switch is housed in a one-piece die-cast metal casing and is environmentally sealed to perform in the harshest road and weather conditions.

Key Features

• Integrated Key Security: The key is removable in the "Off" position, acting as a physical lockout/tagout safety device and theft deterrent.

• Weatherproof Reliability: Equipped with O-ring seals at the base and mounting stem to keep out moisture, dirt, and dust.

• Heavy-Duty Performance: Rated for 180 Amps continuous service and 1000 Amps intermittent (in-rush) at 6V-36V DC.

• Superior Conductivity: Utilizes copper alloy studs and heavy-duty silver-plated contacts for minimal voltage drop and maximum service life.

• Versatile Mounting: Includes a 3/4" diameter mounting stem that fits panels up to 1/4" thick.

Technical Specifications

• Part Number: 51-916 (also available as 51-916P / 51-916EP)

• Circuitry: S.P.S.T. (Single Pole, Single Throw) – Off/On

• Voltage: 6V to 36V DC

• Rating: 180A Continuous / 1000A Intermittent

• Terminals: Two 3/8"-24 Copper Alloy Studs

• Actuator: Removable Key (Includes 1 key)

• Housing: Die-Cast Metal

Recommended Applications

This keyed disconnect switch is highly recommended for:

• Fleet Vehicles: Ensure trucks are not moved without authorization.

• Construction Equipment: Prevent theft and vandalism on job sites.

• Marine & RV: Protect against battery drain and provide an extra layer of security during storage.

• Commercial Trucks: A reliable safety cut-off for maintenance and emergency situations.
