Pollak 52-244 Terminal Block – 4-Gang Non-Feed Through Junction Block (30A, 600V)

Reliable Power Distribution for Heavy-Duty Applications

The Pollak 52-244 is a high-performance 4-Gang Terminal Block designed for secure electrical connections in trucking, marine, and agricultural equipment. Engineered by Pollak—a leader in OEM and aftermarket electrical components—this non-feed-through junction block ensures a stable and organized wiring environment for your vehicle’s electrical systems.

Built for Durability and Precision This 4-circuit terminal block features rugged steel studs mounted on 0.750" centers. To simplify installation, Pollak has integrated a "dog point" design on each stud, which guides the nut into the 10-24 thread effortlessly, preventing cross-threading and saving time in the shop.

Key Features & Benefits:

• 4-Gang Configuration: Provides four independent circuits for versatile power distribution.

• Non-Feed Through Design: Ideal for surface-mount applications where isolation is required.

• High Power Rating: Rated for 30 Amps (DC) and up to 600V VDC, making it suitable for demanding electrical loads.

• High Temperature Resistance: Operates safely in environments up to 250°F (120°C), perfect for engine compartments.

• Easy Installation: Features "dog point" studs to guide nuts quickly and accurately.

• Versatile Fit: Used across light, medium, and heavy-duty trucks, as well as construction and marine equipment.

Technical Specifications:

• Part Number: 52-244 (Bulk) / 52-244P (Packaged)

• Number of Gangs: 4

• Current Rating: 30 Amps DC

• Voltage Rating: 600 VDC

• Temperature Rating: 250°F (120°C)

• Stud Size: 10-24 Thread

• Dimensions: 4.5" Length

• Mounting Centers: 3.75"

• Recommended Torque: 20 in/lb (25 in/lb max)
