Pollak 52-245 Terminal Block – 6-Gang Non-Feed Through Junction Block (30A, 600V)

Heavy-Duty Multi-Circuit Power Distribution

The Pollak 52-245 is a professional-grade 6-Gang Terminal Block designed to provide a secure and organized hub for complex electrical wiring. Whether you are outfitting a heavy-duty truck, a marine vessel, or agricultural equipment, this non-feed-through junction block ensures reliable power distribution for up to six independent circuits.

Precision Engineered by Pollak

Built to withstand harsh environments, this terminal block features rugged steel studs set on 0.750" centers. To eliminate the frustration of cross-threading in tight spaces, Pollak uses a specialized "dog point" stud design that automatically guides the nut into the 10-24 thread for a fast, secure fit every time.

Key Features & Benefits:

• 6-Gang Configuration: Manage six separate electrical circuits from a single, compact location.

• Non-Feed Through Design: Provides safe electrical isolation, ideal for surface mounting on vehicle chassis or firewalls.

• High Performance Ratings: Robust 30 Amp DC current rating and 600V VDC capacity for demanding systems.

• Extreme Temperature Resistance: Rated for operation up to 250°F (120°C), ensuring safety under the hood or in engine compartments.

• Simplified Installation: Features "dog point" studs to prevent cross-threading and speed up assembly.

• Industrial Durability: Trusted by leading OEMs for light, medium, and heavy-duty truck applications.

Technical Specifications:

• Part Number: 52-245 (Bulk) / 52-245P (Packaged)

• Number of Gangs: 6

• Current Rating: 30 Amps DC

• Voltage Rating: 600 VDC

• Operating Temperature: Up to 250°F (120°C)

• Stud Size: 10-24 Thread (Steel Studs)

• Center-to-Center Spacing: 0.750"

• Overall Length: 6.0"

• Mounting Centers: 1.25"

• Recommended Torque: 20 in/lb (25 in/lb maximum)
