Pollak 52-246 Terminal Block – 8-Gang Non-Feed Through Junction Block (30A, 600V)

Expand Your Electrical Infrastructure with Confidence

The Pollak 52-246 is a high-capacity 8-Gang Terminal Block engineered for comprehensive power distribution in demanding environments. This non-feed-through junction block provides a centralized, secure location to manage up to eight independent circuits, making it an essential component for complex wiring projects in heavy-duty trucks, trailers, marine vessels, and RVs.

OEM Quality & Precision Engineering

Manufactured by Pollak, a trusted name in heavy-duty electrical components, the 52-246 is built to withstand the rigors of the road. It features eight rugged steel studs spaced on 0.750" centers. To simplify installation and prevent costly errors, the studs feature a "dog point" design that guides the nut into the 10-24 thread perfectly, virtually eliminating the risk of cross-threading.

Key Features & Benefits:

• 8-Gang Configuration: Provides eight independent circuits for professional-grade wire management.

• Non-Feed Through Design: Perfect for surface mounting where electrical isolation is required on the vehicle chassis.

• High Performance Ratings: Rated for 30 Amps (DC) and up to 600V VDC to handle heavy electrical loads.

• Extreme Heat Tolerance: Operates reliably in temperatures up to 250°F (120°C), making it suitable for engine bay mounting.

• Failsafe Installation: Integrated "dog point" studs guide nuts quickly and securely into place.

• Universal Application: Ideal for light, medium, and heavy-duty trucks, construction equipment, and marine use.

Technical Specifications:

• Part Number: 52-246 (Bulk) / 52-246P (Packaged)

• Number of Gangs: 8

• Current Rating: 30 Amps DC

• Voltage Rating: 600 VDC

• Operating Temperature: Up to 250°F (120°C)

• Stud Size: 10-24 Thread (Steel Studs)

• Overall Length: 7.50"

• Mounting Hole Centers: 6.75"

• Recommended Torque: 20 in/lb (25 in/lb maximum)
