Pollak 52-247 Terminal Block – 10-Gang Non-Feed Through Junction Block (30A, 600V)

The Ultimate Solution for Complex Vehicle Wiring

The Pollak 52-247 is a high-capacity 10-Gang Terminal Block designed for extensive electrical systems in heavy-duty trucks, trailers, and specialized equipment. As the largest in its series, this non-feed-through junction block provides a clean, centralized hub for managing up to ten independent circuits, ensuring your wiring remains organized, accessible, and secure.

Professional Grade Durability

Built by Pollak to meet rigorous OEM standards, the 52-247 is constructed with rugged steel studs mounted on 0.750" centers. To streamline your installation process, each stud features a "dog point" design. This self-guiding tip aligns the nut perfectly with the 10-24 thread, preventing cross-threading and making it easy to work in dark or cramped engine compartments.

Key Features & Benefits:

• 10-Gang Configuration: Maximum circuit capacity for comprehensive power distribution and lighting control.

• Non-Feed Through Design: Ideal for surface-mount applications requiring electrical isolation on the chassis or bulkhead.

• High-Power Capacity: Rated for 30 Amps DC and up to 600V VDC, built for demanding commercial electrical loads.

• Extreme Environment Ready: Operates efficiently in temperatures up to 250°F (120°C), making it perfect for high-heat engine bays.

• Installer-Friendly Design: Integrated "dog point" studs save time and reduce hardware damage during assembly.

• Versatile Application: Trusted for use in light, medium, and heavy-duty trucks, construction machinery, and marine vessels.

Technical Specifications:

• Part Number: 52-247 (Bulk) / 52-247P (Packaged)

• Number of Gangs: 10

• Current Rating: 30 Amps DC

• Voltage Rating: 600 VDC

• Operating Temperature: Up to 250°F (120°C)

• Stud Size: 10-24 Thread (Steel)

• Overall Length: 9.00"

• Mounting Hole Centers: 8.25"

• Recommended Torque: 20 in/lb (25 in/lb maximum)
