Pollak 52-406 6-Position ATC/ATO Blade Type Fuse Panel - 150 Amp Max, Rugged Thermoplastic

Professional-Grade Power Distribution for Heavy-Duty Electrical Systems

The Pollak 52-406 6-Position Fuse Panel provides a central, organized, and rugged solution for managing DC electrical circuits. Engineered for the demanding environments of trucks, buses, RVs, and marine vessels, this compact panel simplifies wiring while offering superior protection for your vehicle's electronics.

This versatile fuse block is designed to accept standard ATC/ATO blade-type fuses as well as manual or automatic reset blade-style circuit breakers. Its high-capacity design supports up to 150 Amps total input, making it an ideal hub for auxiliary lighting, electronics, and power accessories.

Key Features & Benefits:

• High Power Capacity: Features a robust #10-32 stud input rated for a total of 150A max, with output terminals rated for 30A max per circuit.

• Versatile Compatibility: Accepts standard ATC/ATO blade fuses or blade-style circuit breakers for flexible system protection.

• Rugged Construction: Molded from black UL-rated 94V0 thermoplastic, providing excellent heat resistance (-20°F to 150°F) and durability.

• Enhanced Contact Design: Utilizes recessed trifurcated fuse contacts to ensure maximum grip and consistent electrical conductivity.

• Compact & Safe: The "no top cover needed" design saves space, while recessed mounting holes prevent accidental shorts and provide a clean installation.

Technical Specifications:

• Part Number: 52-406 (Bulk) / 52-406P (Packaged)

• Number of Positions: 6

• Input Terminal: #10-32 Stud (150A Max total)

• Output Terminals: .250" x .032" Quick-Connect (30A Max per circuit)

• Material: UL Rated 94V0 Thermoplastic

• Temperature Rating: -20°F to 150°F (-29°C to 65°C)

• Dimensions: 2.47" L x 3.38" W x 0.81" H

• Compliance: UL Recognized, CSA Listed
