Pollak 52-408 8-Position ATC/ATO Blade Type Fuse Panel - 150 Amp Max, Heavy-Duty Distribution Block

Expand Your Power Distribution with Heavy-Duty 8-Circuit Protection

The Pollak 52-408 8-Position Fuse Panel is the high-capacity solution for managing complex electrical systems in commercial trucks, emergency vehicles, and marine applications. This panel provides an organized, central hub for up to eight individual DC circuits, ensuring your auxiliary lights, electronics, and power equipment are safely fused and easy to access.

Designed for maximum versatility, the 52-408 accepts standard ATC/ATO blade fuses as well as manual or automatic reset blade-style circuit breakers. Built with high-impact thermoplastic and precision-engineered contacts, it is designed to withstand the vibration and thermal stress common in heavy-duty trucking environments.

Key Features & Benefits:

• 8-Circuit Capacity: Effortlessly manage multiple auxiliary systems from a single, compact footprint.

• High-Current Performance: Rated for a total input of 150 Amps via a robust #10-32 stud terminal, with 30 Amps max per individual circuit.

• Universal Protection: Compatible with all standard ATC and ATO blade fuses, as well as plug-in style circuit breakers.

• Trifurcated Fuse Contacts: Features recessed, high-grip contacts that ensure a vibration-proof connection and superior electrical conductivity.

• Professional Durability: Manufactured from UL-rated 94V0 thermoplastic, offering a wide operating temperature range of -20°F to 150°F.

• Safety-First Design: Recessed mounting holes prevent accidental shorting, while the design eliminates the need for a bulky top cover in most installations.

Technical Specifications:

• Part Number: 52-408 (Bulk) / 52-408P (Retail Pack)

• Positions: 8

• Input Terminal: #10-32 Stud (150A Max)

• Output Terminals: .250" x .032" Quick-Connect (30A Max per circuit)

• Material: Black UL Rated 94V0 Thermoplastic

• Temperature Rating: -20°F to 150°F (-29°C to 65°C)

• Dimensions: 2.47" L x 4.21" W x 0.81" H

• Approvals: UL Recognized and CSA Listed
